300m Sfp28 Optical Transceiver Sfp28 25g Sr 25.78 Gb/s Datarate
300m Sfp28 Optical Transceiver Sfp28 25g Sr 25.78 Gb/s Datarate
300m Sfp28 Optical Transceiver Sfp28 25g Sr 25.78 Gb/s Datarate
300m Sfp28 Optical Transceiver Sfp28 25g Sr 25.78 Gb/s Datarate
Specifications
Brand Name :
Sourcelight or OEM
Model Number :
SFP28 SR transceiver
Certification :
CE/FCC/RoHS/TUV/UL
Place of Origin :
Shenzhen,China
MOQ :
1PCS
Price :
Get Latest Price
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
500PCS Per Week
Delivery Time :
Shipped in 1 days after PO confirmed
Packaging Details :
10PCS or 20PCS Plastic trays; 1pc gift box.
Product name :
SFP28 SR transceiver
Datarate :
25.78 Gb/s
Distance :
100M OM4 MMF
TX Power :
-8.4~+2.4dBm
Sensitivity :
-10.3dBm
Connector :
Duplex LC UPC
Description

300m Sfp28 Optical Transceiver Sfp28 25g Sr 25.78 Gb/s Datarate

Overview

This Optical Transceiver SFP28 850nm 25GB SR is designed to transmit and receive optical data over 50 μm multimode optical fiber. The 25G SFP28 SR optical module electrical interface is compliant to SFI electrical specifications. The transmitter input and receiver output impedance is 100 Ohms differential. Data lines are internally AC coupled.

sourcelight 25G SFP28 SR optical transceiver module provides differential termination and reduce differential to common mode conversion for quality signal termination and low EMI. SFI typically operates over 200 mm of improved FR4 material or up to about 150mmof standard FR4 with one connector.

Features

  • 25Gb/s serial optical interface

  • 850nm VCSEL transmitter, PIN photo-detector

  • 2-wire interface for management specifications compliant with SFF8472 DDM interface for optical transceivers

  • Operating case temperature: 0 to 70°C

  • All-metal housing for superior EMI performance

  • Low power consumption

  • Advanced firmware allow customer system encryption information to be stored in transceiver

  • Cost effective SFP28 solution, enables higher port densities and greater bandwidth

  • RoHS compliant

Parameter

P/N SFP-25G-SR
Datarate 25G/ps
Distance 300M
Wavelength 850nm
Transmitter VCSEL
Receiver PIN
Media MMF
DDM/DOM YES
Connector LC
Application 25 Gigabit Ethernet
Operating Temperature 0℃~ +70℃
Voltage Supply 3.3V
Certification CE/FCC/RoHS/TUV/UL
Brand sourcelight ,Neuter, OEM

Application

  • High-speed storage area networks

  • Computer cluster cross-connect

  • Inter Rack Connection

300m Sfp28 Optical Transceiver Sfp28 25g Sr 25.78 Gb/s Datarate

Competitive advantage
1. Excellent quality and 3 years warranty
2. Competitive pricing
3. Full compatible (HP/Extreme/Juniper/H3C…)
4. OEM/ODM Customized label
5. Keep stock,Fast delivery
