Passive Direct Attach 100g Qsfp28 Copper Cable / Insulated Electric Cable
Passive Direct Attach 100g Qsfp28 Copper Cable / Insulated Electric Cable
Passive Direct Attach 100g Qsfp28 Copper Cable / Insulated Electric Cable
Passive Direct Attach 100g Qsfp28 Copper Cable / Insulated Electric Cable
Specifications
Brand Name :
Sourcelight or OEM
Model Number :
QSFP28 DAC
Certification :
CE/FCC/RoHS/TUV/UL
Place of Origin :
Shenzhen,China
MOQ :
1PCS
Price :
Get Latest Price
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200PCS Per Week
Delivery Time :
Shipped in 1 days after PO confirmed
Packaging Details :
1pc Independent packaging.
Product name :
QSFP28 DAC
Datarate :
100g
Distance :
0.5~5m passive
Voltage Supply :
3.3v
Connector :
QSFP28 100G
Temperature :
0°C~70°C
Description

Passive Direct Attach 100g Qsfp28 Copper Cable Insulated Electric Cable

Overview
The 100G QSFP28 DAC cables are suitable for very short distances and offer a highly cost-effective way to establish a 100-Gigabit link between QSFP28 ports of QSFP28 switches within racks and across adjacent racks. These cables are used for 100GbE and Infniband standards to maximize performance.
The cable is compliant with SFF-8436 specifications and provides connectivity between devices using QSFP ports.

Features

  • QSFP28 conforms to the Small Form Factor SFF8665

  • 4-Channel Full-Duplex Passive Copper Cable Transceiver

  • Support data rates : 25.78Gb/s (per channel)

  • Maximum aggregate data rate: 100Gb/s (4 x 25.78Gb/s)

  • IEEE 802.3bj 100GEBASE-CR4

  • Copper link length up to 5m

  • Power Supply :+3.3V

  • Low crosstalk

  • I2C based two-wire serial interface for EEPROM signature which can be customized

  • Operating Temperature: 0~ 70 °C

  • RoHS Compliant

Parameter

Package (Form Factor)

100G QSFP28 DAC Copper Cable

Data Rate (typical)

25.78 Gbps/CH

Distance

Up to 5m

Low/High Case Temperature

0°C~70°C

Voltage Supply (typical)

3.3v

Connector

QSFP28

Application

  • 100 Gigabit Ethernet

  • Fiber Channel over Ethernet

  • Data storage and communication industry

  • Switch / router / HBA

  • Enterprise network

  • SAN

  • Data Center Network

Passive Direct Attach 100g Qsfp28 Copper Cable / Insulated Electric Cable

Competitive advantage
1. Excellent quality and 3 years warranty
2. Competitive pricing
3. Full compatible (HP/Extreme/Juniper/H3C…)
4. OEM/ODM Customized label
5. Keep stock,Fast delivery

FAQ(Frequently Asked Questions)
1. Can I have a sample order?What is your MOQ?
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable,We do not have MOQ,1 sample is available.

2. What is the lead time?
For usual products,We keep stock,could ship 1~3 days after PO.For big quantity and special products,Please check lead time with our sales.

3. How do you ship the goods and how long does it take arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.

4. Dose your modules compatible to (HP/Extreme/Juniper,ect)
Yes,we code the optical transceivers compatible to (HP/Extreme/Juniper).

5. What is your payment terms?
Usually,we need prepayment by T/T,West Union or Cash.Could also support Credit terms like NET 7DAYS,NET30 DAYS or COD(cash on delivery) for old customers after credit application is approved.

6. What is your warranty time
We promise 3 years warranty for all products shipped from us.

7. Could I return the products if there is a quality problem?
Yes,if there is a quality problem happen,including products defects,.we could accept free exchange or return and refund.
