100g Qsfp28 Dac Copper Direct Attach Cable For Data Center And Fttx
100g Qsfp28 Dac Copper Direct Attach Cable For Data Center And Fttx
100g Qsfp28 Dac Copper Direct Attach Cable For Data Center And Fttx
100g Qsfp28 Dac Copper Direct Attach Cable For Data Center And Fttx
Specifications
Brand Name :
Sourcelight or OEM
Model Number :
100G QSFP28 dac
Certification :
CE/FCC/RoHS/TUV/UL
Place of Origin :
Shenzhen,China
MOQ :
1PCS
Price :
Get Latest Price
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200PCS Per Week
Delivery Time :
Shipped in 1 days after PO confirmed
Packaging Details :
1pc Independent packaging.
Product name :
100G QSFP28 DAC
Datarate :
25.78Gb/s (per channel)
Distance :
Up to 5M For Passive
Voltage Supply :
3.3v
Connector :
QSFP28
Temperature :
0°C~70°C
Description

100g Qsfp28 Dac Copper Direct Attach Cable For Data Center And Fttx

Overview
The 100G QSFP28 DAC cable assemblies are high performance, cost effective I/O solutions for LAN, HPC and SAN. The high speed cable assemblies meet and exceed 100 Gigabit Ethernet, InfiniBand EDR and temperature requirements for performance and reliability.
The cable is compliant with SFF-8436 specifications and provides connectivity between devices using QSFP ports.

Features

  • QSFP28 conforms to the Small Form Factor SFF8665

  • 4-Channel Full-Duplex Passive Copper Cable Transceiver

  • Support data rates : 25.78Gb/s (per channel)

  • Maximum aggregate data rate: 100Gb/s (4 x 25.78Gb/s)

  • IEEE 802.3bj 100GEBASE-CR4

  • Copper link length up to 5m

  • Power Supply :+3.3V

  • Low crosstalk

  • I2C based two-wire serial interface for EEPROM signature which can be customized

  • Operating Temperature: 0~ 70 °C

  • RoHS Compliant

Parameter

Package (Form Factor)

100G QSFP28 DAC Copper Cable

Data Rate (typical)

25.78 Gbps/CH

Distance

Up to 5m

Low/High Case Temperature

0°C~70°C

Voltage Supply (typical)

3.3v

Connector

QSFP28

Application

  • 100 Gigabit Ethernet

  • Fiber Channel over Ethernet

  • Data storage and communication industry

  • Switch / router / HBA

  • Enterprise network

  • SAN

  • Data Center Network

100g Qsfp28 Dac Copper Direct Attach Cable For Data Center And Fttx

FAQ(Frequently Asked Questions)
1. Can I have a sample order?What is your MOQ?
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable,We do not have MOQ,1 sample is available.

2. What is the lead time?
For usual products,We keep stock,could ship 1~3 days after PO.For big quantity and special products,Please check lead time with our sales.

3. How do you ship the goods and how long does it take arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.

4. Dose your modules compatible to (HP/Extreme/Juniper,ect)
Yes,we code the optical transceivers compatible to (HP/Extreme/Juniper).

5. What is your payment terms?
Usually,we need prepayment by T/T,West Union or Cash.Could also support Credit terms like NET 7DAYS,NET30 DAYS or COD(cash on delivery) for old customers after credit application is approved.

6. What is your warranty time
We promise 3 years warranty for all products shipped from us.

7. Could I return the products if there is a quality problem?
Yes,if there is a quality problem happen,including products defects,.we could accept free exchange or return and refund.
