Purple Om4 Purple Mpo Mtp To Lc Fiber Optic Patch Cables Fanout 12 Cores
Purple Om4 Purple Mpo Mtp To Lc Fiber Optic Patch Cables Fanout 12 Cores
Purple Om4 Purple Mpo Mtp To Lc Fiber Optic Patch Cables Fanout 12 Cores
Purple Om4 Purple Mpo Mtp To Lc Fiber Optic Patch Cables Fanout 12 Cores
Specifications
Brand Name :
Sourcelight or OEM
Model Number :
MPO 24 Cores Connector
Certification :
IS09001-2008.ROHS
Place of Origin :
Shenzhen,China
MOQ :
1pcs
Price :
Get Latest Price
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Delivery Time :
5000 Pcs Per Month
Packaging Details :
PE bag, carton box, wooden pallet
Type :
MPO/LC/SC/FT
Mode :
OM3
Insertion Loss :
0.3dB
Cable Color :
Purple
Cable Diameter :
3.0mm Or 2.0mm
Polarity :
A,B,C
Description

Purple Om4 Purple Mpo Mtp To Lc Fiber Optic Patch Cables Fanout 12 Cores

Product Description

MTP/MPO-LC OM4 fanout patch cords are mainly used in high-density data centers, fiber to the building (FTTB) ,optical splitter / 40G/100G SFP / SFP + optical transceiver device to flexible connection between different modules. equipment and systems . so that the optical signal can transmit the desired channel, to achieve and complete a predetermined or desired purpose and requirements.

Advantages
  • Imported production and test equipments:EXFO IL&RL Tester/ Domaille Grinding Machine/ SENKO 3D Interferometer
  • Pretty high return loss:≥45dB
  • 5-year Experience R&D Team
  • Customized Production and Service
  • 40G/100G Data Center Solution
Application
  • Data center infrastructure
  • Storage area network
  • Emerging 40 & 100Gps Protocols
  • Parallel optics
  • Enterprise network cabling systerm
Technical Parameter
Item Technical Parameter
Connector MPO (Female) LC
Operation Temperature -40°C ~ +80°C
Storage Temperature -40°C ~ +85°C
Insertion Loss

SM: ≤ 0.75dB (standard value),

≤0.35dB (typical value);

MM:≤ 0.50dB (standard value),

≤0.35dB (typical value);

SM:≤ 0.2dB;

MM:≤ 0.2dB;
Return Loss

SM:≥60dB;

MM:≥35dB;

SM:≥60dB;

MM:≥35dB;
The MPO end type Male: with guide pin; Female: without guide pin
Fiber count 8,12&24 MT fiber
The other end of the connector type MPO-female , MPO-male , FC , SC , ST , MU , LC , E2000
Fiber mode Single-mode(G652,G655,G657), multi-mode (50, 62.5, OM2, OM3, OM4)
Fiber cable type 250um ribbon fiber,ribbon cable,Bundle fiber optic cable

Purple Om4 Purple Mpo Mtp To Lc Fiber Optic Patch Cables Fanout 12 Cores
