1ch BIDI 3G/HD-SDI video to fiber extender,optical to Bi-directional 3G-SDI to fiber mutlplexer,TV production BIDI SDI
1ch BIDI 3G/HD-SDI video to fiber extender,optical to Bi-directional 3G-SDI to fiber mutlplexer,TV production BIDI SDI
Specifications
Brand Name :
BEYOND
Model Number :
BY-SDI-3G-1VV
Certification :
CE FCC
Place of Origin :
ShenZhen,China
MOQ :
1 pair
Price :
Negotiable
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
1000 pairs per week
Delivery Time :
1-3 working days
Packaging Details :
paper box packing for export,including one transmitter,one receiver,one power adapter,one user's manual
Signal format :
SMPTE 424M, SMPTE 292M, SMPTE 259M
Data rate :
270Mbit/s - 1.48Gbit/s - 3Gbit/s
Fiber interface :
ST/LC/FC optional
Transmitter wavelength :
CWDM wavelength optional
Input power :
DC 12V
Net weight :
1.5 KG
Dimensions :
168mmx154mmx45mm
Description

Not like the Dimension?too big?It's not a problem,please send your drawing,we will customized a nice size for your requirement.Also can printing your lOGO.

BIDI 3G-SDI video to fiber multiplexer (1-ch bidi 3G/HD-SDI video to fiber multiplexer)includes a transmitter and a receiver. The system transports 1-ch BIDI 3G/HD-SDI signal from the camera to the Base Station and a return video (3G/HD-SDI) through a single FC/ST/LC fi ber.The system puts the signals needed for multi-camera 3G/HD-SDI production on a SMPTE cable, insuring robust, trouble-free connectivity on any studio or remote production.

Both transmitter and receiver provide equalizing and reclocking at input unit in order to re-construct the signal for consistent quality. Besides, with Transwan advanced fiber technology, VSDI can easily pass pathological pattern to prove its complete transmission.

  • 4 Channel HD-SDI High density digital audio/video fiber transmission
  • Handle all Pathological patterns
  • SD, HD, 3G input auto indentification,support three datarate 270Mbit/s - 1.48Gbit/s - 3Gbit/s；support 1080P 3Gbps HD-SDI format
  • Support SMPTE-424M 3Gbps HD-SDI,SMPTE-292M HD-SDI , SMPTE-259M SDI
  • 10~60Km on single Mode Fiber transmission
  • 1470~1610nm CWDM wavelengths optional.

Specifications:

SDI input/output
Signal format SMPTE 424M, SMPTE 292M, SMPTE 259M
Data rate 270Mbit/s - 1.48Gbit/s - 3Gbit/s
Cable Equalization

Automatic cable EQ (Belden 1694A cable)

250m @ 270Mbit/s, 140m @ 1.5Gbit/s, 80m @ 3Gbit/s
SDI interface BNC 75 Ohm
Fiber interface ST/SC/FC
Number of tranmitter channel 4
Transmitter wavelength CWDM wavelength optional
Transmitter output power -5~0dBm(0±3dBm optional)
Number of receiver output 4
Receiver sensitivity -18dBm～0 dBm
General index
Input power DC 12V
Power consumption 8W
Work Temp -20°C to 55°C
Storage Temp -40°C to 85°C
humidity 0 ~ 95% (non-condensing)
Net weight 2.5KG/pair
Dimensions 168mm×154mm×45mm
