Dry/wet contact closure over fiber converter,alarm/TTL/ dry Contact Closure input, relay output to fiber optical convert
Dry/wet contact closure over fiber converter,alarm/TTL/ dry Contact Closure input, relay output to fiber optical convert
Dry/wet contact closure over fiber converter,alarm/TTL/ dry Contact Closure input, relay output to fiber optical convert
Dry/wet contact closure over fiber converter,alarm/TTL/ dry Contact Closure input, relay output to fiber optical convert
Dry/wet contact closure over fiber converter,alarm/TTL/ dry Contact Closure input, relay output to fiber optical convert
Dry/wet contact closure over fiber converter,alarm/TTL/ dry Contact Closure input, relay output to fiber optical convert
Dry/wet contact closure over fiber converter,alarm/TTL/ dry Contact Closure input, relay output to fiber optical convert
Dry/wet contact closure over fiber converter,alarm/TTL/ dry Contact Closure input, relay output to fiber optical convert
Specifications
Brand Name :
Beyondopto
Model Number :
BY-4KK
Certification :
CE FCC ROSH
Place of Origin :
ShenZhen,China
MOQ :
1 pair
Price :
Negotiable
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
1000 pairs per week
Delivery Time :
1-2 working days
Packaging Details :
Paper box packing for export
Wavelength :
1310nm&1470nm~1610nm
Optical connector :
FC、ST、SC (optional)
Distance :
0~2KM (MM) / 0~100KM (SM)
Dimensions: :
175mm×154mm×30mm
Weight: :
1.5kg
Description

4 BIDI Contact Closure To Fiber Optic support 4 Channels BIDI contact closure over one multi-mode or single-mode optical fiber. These fiber optic transmitterand fiber optic receiver are typically used in applications with Access Control System, Alarm Event Triggering, Building Automation and Environmental Control Systems, Fire & Alarm Systems, PIR signal Transmission, Traffic Signal Control Equipment, etc, and are available for stand-alone or rack-mount installations. FC, ST or SC optical connectors is optional.

Plug and Play design ensures adjustment-free installation and operation, and optical adjustments are never required. LED indicators are provided to instantly monitor the system operating status.

Features

• Support Point-to-Point or Daisy-Chain connection
• Dry Contact Closure or TTL data over one fiber
• Multimode Fiber Support for Distances up to 2 km
• Single-Mode Fiber Support for Distances up to 100 km
• LED Status Provide Rapid Indication of Operating Parameters
• No EMI or RFI and no ground loops
• Stand alone or rack-mount
• Produce according to customer's specifications,providing OEM

Opitcal:

Wavelength 1310nm&1470nm~1610nm
Output Power -14~ -8dBm / -5~0dBm
Optic fiber 50/125u multimode,62.5/125u multimode,9/125u single mode
Rx sensitivity -30dBm
Optical connector FC,ST,SC (optional)
Distance 0~2KM (MM) / 0~100KM (SM)

Contact Closure:

Connector Standard terminal lead
Signal input alarm, Binary input, support TTL,RS-232/422/485 or passive dry Contact Closure
Signal output Arbitrary alarm, Binary output, support TTL,RS-232/422/485 or relay output

Electrical & Mechanical
Input Power Requirements: DC 5V@2A
Power Adapter: AC 90V~240V
Power Consumption: < 5W
Stand-Alone Dimensions: 175mm×154mm×30mm
Shipping Weight: (include Transmitter & Receiver ) 1.5kg

Environmental
Operating Temperature: -20°C ~ +75°C
Storage Temperature: -40°C ~ +85°C
Relative Humidity: 0% ~ 95% (non-condensing)
MTBF: >100,000 hours

System connection diagram

Dry/wet contact closure over fiber converter,alarm/TTL/ dry Contact Closure input, relay output to fiber optical convert
