Specifications
Brand Name :
BANGHAO
Certification :
ISO9001
Place of Origin :
China
MOQ :
1set
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
3,000 sets per year
Delivery Time :
15 days after we receive your deposit
Packaging Details :
Wooden Boxes, Vacuum Aluminum Packing
Name :
Infrared Sorting Machine
Accuracy :
more than 99.99%
After-sales service provided :
Engineers available to service machinery overseas,Free spare parts,Online support,Overseas service center available,Video technical support
Voltage :
220V 50HZ,220v/50hz,220v/110v,380V,24V
Warranty :
1 Year
Sorting accuracy :
≥99.9
Description

Intelligent NIR Plastic Sorting Machine

Product Description

Intelligent NIR Plastic Sorting machine specially produced for recycling industry.

This machine adopts high-pixel image sensor, equipped with high-speed automatic identifying and analysing system, it can sort needed material from rejected one, so that material quality is greatly promoted.

Operational Principle

Material goes through hopper into the machine, shaken by the vibration device, the material slides through distributing box, an then pass through detector and background board. Under the light resource, the light sensor receives compound light from the material, and the system sends out signals, driving the movement of the ejection valve, and remove off color material to the eject chamber. Accepted material freely falls down to the finished-product chamber, so that the material is precisely sorted.

Device Characteristic

* Efficiently sort needed material from rejected one.

* Separate various colors;

* Strengthened spout and air jet design for high per-cent contaminated material, durable and dependent;

* Adopts high-resolution image sensor, equipped with high-speed automatic identifying and analysing system;

* New type touch-screen operation platform, big colorful screen and user-friendly operation interface, can easily change sorting precision to the best quality;

* Adopts latest software, highly precise sorting, with low product loss;

* Except for some traditional functions like double-face sorting and second-time sorting, it also has more intelligentized functions, which simplify operation and handle.

Applications

* PET bottle flake

* HDPE/LDPE bottle flake

* ABS/PS/PC engineering plastic

Technical Specification

Model Throughput Material size Power Machine size Weight
Rock 180F 1-3T/H 2*2-30*30mm 1.8KW 1455*1597*2142mm 940KG
Rock 300F 2-5T/H 2*2-30*30mm 2.4KW 2075*1597*2142mm 1330KG
Rock 420F 3-8T/H 2*2-30*30mm 3.5KW 2625*1597*2142mm 1650KG
