User Friendly Intelligent Plastic Sorting Equipment For Recycling Industry
User Friendly Intelligent Plastic Sorting Equipment For Recycling Industry
User Friendly Intelligent Plastic Sorting Equipment For Recycling Industry
User Friendly Intelligent Plastic Sorting Equipment For Recycling Industry
Specifications
Brand Name :
BANGHAO
Certification :
ISO9001
Place of Origin :
China
MOQ :
1set
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
3,000 sets per year
Delivery Time :
15 days after we receive your deposit
Packaging Details :
Wooden Boxes, Vacuum Aluminum Packing
Product name :
Plastics Color Sorter
Accuracy :
more than 99.99%
Type :
industry color sorter,optical plastic sorter,BCSD Plastic Color Sorter
Voltage :
220V 50HZ,220v/50hz,220v/110v,380V,24V
Warranty :
1 Year
Application :
plastics
Sorting accuracy(%) :
≥99
Usage :
plastic color sorting
After-sales service provided :
Engineers available to service machinery overseas,Free spare parts,Online support,Overseas service center available,Video technical support
Description

Intelligentized Plastic Sorting Machine

Product Description

Intelligentized plastic sorting machine specially produced for recycling industry.

This machine adopts high-pixel image sensor, equipped with high-speed automatic identifying and analyzing system, it can sort needed material from rejected one, so that material quality is greatly promoted.

Application:

* PET bottle flake

* HDPE/LDPE bottle flake

* ABS/PS/PC engineering plastic

Technical Specifications

Model CF3+ CF5+ CF7+
Capacity(t/h) 1-1.5 1.5-2.5 2.5-4
Number of Execution Units 180 300 420
Size of Sorting(mm) 2*2-30*30 2*2-30*30 2*2-30*30
Power(kw) 1.8 2.4 3.5
Dimensions(L*W*H)(mm) 1455*1597*2142 2075*1597*2142 2625*1597*2142
Weight(kg) 940 1330 1650

Operational Principle

Material goes through hopper into the machine, shaken by the vibration device, the material slides through distributing box, an then pass through detector and background board.

Under the light resource, the light sensor receives compound light from the material, and the system sends out signals, driving the movement of the ejection valve, and remove off color material to the eject chamber. Accepted material freely falls down to the finished-product chamber, so that the material is precisely sorted.

Sorting Example

Device Characteristic

* Separate various colors;

* Efficiently sort needed material from rejected one;

* Adopts latest software, highly precise sorting, with low product loss;

* Strengthened spout and air jet design for high per-cent contaminated material, durable and dependent;

* Adopts high-resolution image sensor, equipped with high-speed automatic identifying and analysing system;

* New type touch-screen operation platform, big colorful screen and user-friendly operation interface, can easily change sorting precision to the best quality;

* Except for some traditional functions like double-face sorting and second-time sorting, it also has more intelligentized functions, which simplify operation and
