SFP 10G 40km Duplex WDM CWDM DWDM Transceiver Module
SFP 10G 40km Duplex WDM CWDM DWDM Transceiver Module
SFP 10G 40km Duplex WDM CWDM DWDM Transceiver Module
SFP 10G 40km Duplex WDM CWDM DWDM Transceiver Module
SFP 10G 40km Duplex WDM CWDM DWDM Transceiver Module
SFP 10G 40km Duplex WDM CWDM DWDM Transceiver Module
Specifications
Place of Origin :
Hubei, China
Brand Name :
YXFiber
Model Number :
YXF-PX94-LCD
Certification :
CE RoHS FCC
Supply Ability :
100000pcs per month
Packaging Details :
10pcs in Plastic tray
MOQ :
1pcs
Price :
$120.00 - $160.00 / Piece
Delivery Time :
1~3working days after payment
Payment Terms :
T/T
Type :
Fiber Optic Transceivers
No. of Fiber :
2.
Use :
FTTH
Supply Voltage :
3.3V
Power :
0~4dBm
Data rate :
10Gbps
Distance :
40km
Transmission distance :
C30
Interface :
Duplex LC
Fiber Type :
SMF
DDMI :
yes
Warranty :
1 Year
Port :
Wuhan
Description
Product Description

SFP 10G 40km Duplex WDM CWDM DWDM Transceiver Module

DWDM SFP+ 10G 40km C30 DOM

Features:

  • DWDM PON network
  • ITU-T DWDM grid wavelengths
  • Data rate selectable ≤4.25Gbps or 9.95Gbps to 11.3Gbps bit rates
  • Temperature Stabilized DWDM DFB Transmitterd
  • Multi channels optional
  • Low Power Dissipation 1.5W Maximum
  • Excellent ESD protection
  • -5ºC to 70ºC Operating Case Temperature
  • Single 3.3V power supply
  • Diagnostic Performance Monitoring of module temperature,
  • Supply Voltages, laser bias current, transmit optical power,
  • receive optical power
  • RoHS compliant and lead free

Applications:

  • DWDM optical links
  • DWDM PON network

Specification:

Product type Data Rate Wavelength Reach LD TX Power PD Rx Sens
DWDM SFP+ 10G 15xx.xx nm 40Km EML -1~3dbm PIN <-20dbm
DWDM SFP+ 10G 15xx.xx nm 80Km EML 0~4dbm APD <-24dbm
DWDM XFP 10G 15xx.xx nm 40Km EML -1~3dbm PIN <-16dbm
DWDM XFP 10G 15xx.xx nm 80Km EML 0~4dbm APD <-24dbm

Application

SFP 10G 40km Duplex WDM CWDM DWDM Transceiver Module

Company Information

SFP 10G 40km Duplex WDM CWDM DWDM Transceiver Module

Production Flow

SFP 10G 40km Duplex WDM CWDM DWDM Transceiver Module

Product tags

dwdm xfp transceiver

,

cwdm gbic transceiver module

,

120km dwdm sfp transceiver
