GLC-BX-120D GLC-BX-120U DFB Laser DDM CISCO Compatible Transceivers
GLC-BX-120D GLC-BX-120U DFB Laser DDM CISCO Compatible Transceivers
GLC-BX-120D GLC-BX-120U DFB Laser DDM CISCO Compatible Transceivers
GLC-BX-120D GLC-BX-120U DFB Laser DDM CISCO Compatible Transceivers
GLC-BX-120D GLC-BX-120U DFB Laser DDM CISCO Compatible Transceivers
GLC-BX-120D GLC-BX-120U DFB Laser DDM CISCO Compatible Transceivers
GLC-BX-120D GLC-BX-120U DFB Laser DDM CISCO Compatible Transceivers
GLC-BX-120D GLC-BX-120U DFB Laser DDM CISCO Compatible Transceivers
GLC-BX-120D GLC-BX-120U DFB Laser DDM CISCO Compatible Transceivers
GLC-BX-120D GLC-BX-120U DFB Laser DDM CISCO Compatible Transceivers
GLC-BX-120D GLC-BX-120U DFB Laser DDM CISCO Compatible Transceivers
GLC-BX-120D GLC-BX-120U DFB Laser DDM CISCO Compatible Transceivers
Specifications
Brand Name :
YXFiber
Model Number :
YXF-GE-B45L-120D, YXF-GE-B54L-120D
Certification :
CE RoHS FCC
Place of Origin :
Hubei, China
MOQ :
1pcs
Price :
$36.00
Payment Terms :
T/T
Supply Ability :
200000pcs per month
Delivery Time :
1~3working days after payment
Packaging Details :
10pcs in Plastic tray
Type :
Fiber Optic Transceivers
No. of Fiber :
1.
Use :
FTTX
Supply Voltage :
3.3V
Data rate :
1.25Gbps
Power :
4~-1dBm
Wavelength :
1490nm/1550nm
Transmission distance :
120km
Interface :
BIDI LC
Fiber Type :
SMF
DDMI :
Yes
Warranty :
1 Year
Selling Units :
Single item
Single package size  :
22X5X6 cm
Single gross weight :
0.060 kg
Package Type :
10pcs/ anti-static box
Description
Product Description

1GB WDM SFP 120km GLC-BX-120D/GLC-BX-120U DFB lazer SM DDM cisco compatible transceiver Module

Technical Parameters Descriptions Unit
Model Number

YXF-GE-B45L-100D

YXF-GE-B54L-100D

 PCS
Fiber type SMF
Form Factor BIDI SFP
Data Rate 1.25 Gbps
Wavelength TX1310/RX1550 nm
Distance 120 KM
Sensitivity <-30.0 dBm
Connector LC/SC
Laser DFB/PIN
DDM Yes
Output Power 5~0 dBm
Power Supply 3.3 V
Temperature 0~70 °C
Certificate CE,ISO9001,FCC,SGS,ROHS
Warranty 1 Year

Features

l Up to 120km transmission on SMF

l Up to 1.25Gbps

l DFB laser and PIN receiver

l Single LC/SC receptacle optical interface compliant

l 2-wire interface for integrated Digital Diagnostic monitoring

l Hot pluggable

l Very low EMI and excellent ESD protection

l +3.3V power supply

l Power consumption less than 1.0W

l Operating case temperature: 0~+70°C

Applications

l High-speed storage area networks

l Computer cluster cross-connect

l Custom high-speed data pipes

Compliance

l Compliant with IEEE 802.3Z

l Compliant with MSA SFF-8472

l Compliant with SFP MSA

Specification

Absolute Maximum Ratings

Parameter

Symbol

Min.

Max.

Unit

Notes

Storage Temperature

TS

-40

+85

℃

Supply Voltage

VCC3

0

3.6

V

Relative Humidity

RH

5

+85

%

Note1

Rx Input Average Power

Pmax

-

+1

dBm
