Specifications
Place of Origin :
Shenzhen（China）
Brand Name :
DYS/OEM
Certification :
IS09001-2015.ROHS
Model Number :
SC/UPC
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
Individual box or according to customer's request
Delivery Time :
3-5 work days
Payment Terms :
L/C,T/T
Supply Ability :
500000PCS / Month
Description

SC/UPC Singlemode Duplex Blue Fiber Optic Adapter With Shutter For Cable TV Network

Quick Details:

Model Number: SC/UPC

Boby Color: Blue

Package: Plastic box

Delivery Detail:In 3 days

Specification

DYS FIBER OPTIC's Fiber optic adapter fiber optic adapter pdoduce diversfied types of adaptersincluding FC,SC,ST,LC,MU,MTRJ,E2000,DIN,D4,MPO,FC-SC,FC-ST,SC-ST,LC-FC,LC-SC etc.Integrative construction of connector,good and low insertion loss and high returnloss can satify the requirements of fast,exact,lastingand stable connection in different environments!

Application:

(1) Fiber Optic Transmission Network;

(2) Cable TV network;

(3) Optical Fiber LAN;

(4) Optical fiber testing instrument;

(5) ODF, rack-mounted and wall-mounted optical fiber wiring unit.

Performance Index:

Type

LC, SC, FC, MU, ST, SC-ST,
FC-ST, FC-SC, FC-LC, FC-MU

MTRJ

E2000

Mode

Single-Mode (SM)

Multi-Mode

(MM)

SM

MM

SM

PC

UPC

APC

PC

PC

UPC

PC

PC

APC

Insertion Loss(dB)

≤0.3

≤0.2

≤0.3

≤0.2

≤0.3

≤0.2

≤0.2

≤0.3

≤0.3

Return Loss(dB)

≥45

≥50

≥60

≥30

≥45

≥50

≥35

≥55

≥75

Interchangeability(dB)

≤0.2

≤0.2

≤0.2

Repeatability (dB)

≤0.2

≤0.2

≤0.2

Durability

>1000

>1000

>1000

Operating
Temperature(°C)

-40~75

-40~75

-40~75

Storage
Temperature(°C)

-45~85

-45~85

-45~85

SC/UPC Singlemode Duplex Blue Fiber Optic Adapter With Shutter For Cable TV Network

Technical Parameters:

Repeatability ≤0.2dB;

Interchangeability ≤0.2dB;

Sleeve Material: ceramic sleeve or phosphor bronze sleeve;

Insertion Loss ≤0.2dB.

Competitive Advantage

DYS strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, productsexported to Europe and the United States and Southeast Asian countries.
