Fiber Ribbon Optical Fiber Patch Cord FTTH Pigtail For CATV Systems
Fiber Ribbon Optical Fiber Patch Cord FTTH Pigtail For CATV Systems
Fiber Ribbon Optical Fiber Patch Cord FTTH Pigtail For CATV Systems
Fiber Ribbon Optical Fiber Patch Cord FTTH Pigtail For CATV Systems
Fiber Ribbon Optical Fiber Patch Cord FTTH Pigtail For CATV Systems
Fiber Ribbon Optical Fiber Patch Cord FTTH Pigtail For CATV Systems
Fiber Ribbon Optical Fiber Patch Cord FTTH Pigtail For CATV Systems
Fiber Ribbon Optical Fiber Patch Cord FTTH Pigtail For CATV Systems
Specifications
Place of Origin :
shenzhen
Brand Name :
DYS/OEM
Certification :
IS09001-2015.ROHS
Model Number :
MPO/PC-SC
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
Individual box or according to customer's request
Delivery Time :
IN 3 Days
Payment Terms :
L/C,T/T
Supply Ability :
2000/WEEKS
Description

Fiber Ribbon Optical Fiber Patch Cord FTTH Pigtail For CATV Systems

Quick Details:

1.Fiber type:MPO/PC-MPO/SC

2.Model Number: PC-SC

3.Inserion Loss: <0.3db

4.Return Loss: >45db

5.Color:Yellow

6.Jacket Materials<LSZH/OFNR/PVC

7.Ferrule Materials:Ceramic

Applications

1.Access Network

2.Telecom/CATV Systems

3.FTTx

Fetures:

1.Price-Competitive

2.Low Insertion Loss & PDL

3.Factory-terminated and Tested

4.Fiber Options: G.652 /G.657/OM1/OM2/OM3 and PM Panda Fiber

5.Connector Options: FC/SC/LC/ST/MU/E2000/MT-RJ/MPO/MTP

6.Polishing Options: PC/UPC/APC

7.Feature Connector with Ceramic Ferrules

Specifications

Parameters

Standard Fiber Cable Assemblies

Fiber Type

SM(G.652/G.657A)

MM(OM1/OM2/OM3)

Jacket Materials

LSZH/OFNR/PVC

Connector Type

SC/LC/ST/LC/MU/MTRJ/MPO/E2000

Ferrule Materials

Ceramic

Testing Wavelengths

1310±30/1550±30nm

850±30/1300±30nm

Insertion Losss(dB)
TIA/EIA-455-107

≤ 0.3dB
(PC/UPC/APC)

≤ 0.3dB
(PC/UPC)

Return Loss(dB)
TIA/EIA-455-107

≥45dB(PC/UPC)
≥55dB(APC)

≥35dB(PC/UPC)

Exchangeability

≤ 0.2dB

Cable Assemblies

Pigtail/Simplex/Duplex/Fan-out Patchcord

Operating Temperature (° C)

-10~ + 70

Storage Temperature (° C)

-40 ~ +85

Package

1unit/bag

*All values specified are with connectors.

Fiber Ribbon Optical Fiber Patch Cord FTTH Pigtail For CATV Systems

Fiber Ribbon Optical Fiber Patch Cord FTTH Pigtail For CATV Systems

Competitive Advantage

DYS strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, productsexported to Europe and the United States and Southeast Asian countries.

Certificate of qualification

Fiber Ribbon Optical Fiber Patch Cord FTTH Pigtail For CATV Systems
