SC APC Connectors Optical Fiber Splitter 1x8 G657 Single Mode
SC APC Connectors Optical Fiber Splitter 1x8 G657 Single Mode
SC APC Connectors Optical Fiber Splitter 1x8 G657 Single Mode
SC APC Connectors Optical Fiber Splitter 1x8 G657 Single Mode
SC APC Connectors Optical Fiber Splitter 1x8 G657 Single Mode
SC APC Connectors Optical Fiber Splitter 1x8 G657 Single Mode
SC APC Connectors Optical Fiber Splitter 1x8 G657 Single Mode
SC APC Connectors Optical Fiber Splitter 1x8 G657 Single Mode
Specifications
Brand Name :
DYS/OEM
Model Number :
plc fiber optical splitter 1x8
Certification :
IS09001-2015.ROHS
Place of Origin :
shenzhen
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T or LC, D/A, D/P, Western Union, MoneyGram
Supply Ability :
500000PCS / Month
Delivery Time :
3-5 work days
Packaging Details :
1pcs/box
Connector Type :
SC/APC
Use :
FTTH
Application :
FTTH FTTB FTTX Network
Operating Wavelength(nm) :
1260~1650
Operating temperature :
-40℃ to 85℃
Fiber Type :
G657A1 or as customers' order
Color :
Customized Service
Return Loss (dB) :
55/50
Single-Mode Fiber :
G652 G657
Fiber diameter :
0.9mm
Description

SC APC Connectors Optical Fiber Splitter 1x8 G657 Single Mode

mini package SC APC connectors plc fiber optical splitter 1x8

Description
PLC optical splitter made by the semiconductor process. Optical wave guide needle is located at the top of the chip, in the chip to achieve shunt, PLC optical splitter can be divided into cassette, chip, rack, etc type.

Specification

Parameters 1×8
Operating Wavelength (nm) 1260~1650
Fiber Type SMF-28e or customer specified
Insertion Loss (dB)(S/P Grade) 10.5/10.2
Loss Uniformity (dB) 0.8
Return Loss (dB) (S/P Grade) 50/55
Polarization Dependent Loss(dB) 0.3
Directivity (dB) 55
Wavelength Dependent Loss(dB) 0.3
Temperature Stability(-40~85 ℃)(dB) 0.5
Operating Temperature (℃) -40~85
Storage Temperature (℃) -40~85
Packaging Dimension (mm) (L×W×H) 40×4×4

SC APC Connectors Optical Fiber Splitter 1x8 G657 Single Mode

SC APC Connectors Optical Fiber Splitter 1x8 G657 Single Mode
