Specifications
Brand Name :
NEWBRIDGE
Model Number :
ND1106-C01
Certification :
CE,FCC
Place of Origin :
SHENZHEN,CHINA
MOQ :
1PC
Price :
Negotiation
Packaging Details :
packing can be done by customer's requested, usually used in carton
Delivery Time :
According to the quantiy and stocking , 3-4 working days after payment
Payment Terms :
T/T , Western Union
Supply Ability :
According to the different products , the monthly output is different
Impedance :
75Ω
Power Supply :
DC 5V
Working Temperature :
- 25 ~ 75 ℃
Working Humidity :
10 ~ 60%
Product Dimension :
118*82*27mm
Output Video Systems :
PAL/NTSC
Description

HDMI to Composite / S-Video Converter with L/R Stereo Audio output

Introduction

This converter box is designed to convert HDMI to either Composite Video or S-Video. It allows the devices only equipped HDMI output to be connected to analog TV. It is mostly applied in AV equipment testing.

Feature

★ Input HDMI Resolution:480p(60Hz), 576P(50Hz), 720p(50Hz/60Hz),1080i(50Hz/60Hz), 1080p(50Hz/60Hz)

★ Output Signal: Conposite Video (1.0Vpp), S-Video (Y:1.0Vpp, C:0.3Vpp);

★ Output Video Systems: PAL/NTSC;

★ Output Video Impedance:75 Ω;

★ Compatible with HDMI 1.3 and HDCP;

★ Power Supply: DC 5V;

★ Working Temperature:-25 ℃~75℃

★ Working Humidity: 10%~60%

★ Product Dimension: 118*82*27mm(L*W*H)

Interface Specification

HDMI to Composite / S-Video Converter with L/R Stereo Audio output Fiber Optic Transceiver

①HDMI In: To connect HD device sources

②PAL/NTSC Switch: select PAL or NTSC

③ CVBS/S-Video Switch: Select Composite Video or S-Video as

④LED: Power indicator

⑤DC 5V: To connect DC 5V power supply

⑥S-Video Out: S-Video output

⑦CVBS Out: Composite Video output

⑧L/R: Audio L/R output

Accessories

Item

Qty(pcs)

Remark

Power Supply

 1 DC 5V

AV Cable

 1

S-Video Cable

 1

User Manual

 1

Connection Image

HDMI to Composite / S-Video Converter with L/R Stereo Audio output Fiber Optic Transceiver

Note:This product doesn’t support simultaneous output of Composite Video and S-Video. Please select either one of them by switch Button on the unit.
