HD-SDI Distribution Amplifier 1 x 2 SD/HD -SDI Repeaters

Specifications

Brand Name :

NEWBRIDGE

Model Number :

ND1102BD

Certification :

CE,FCC

Place of Origin :

SHENZHEN,CHINA

MOQ :

1PC

Packaging Details :

packing can be done by customer's requested, usually used in carton

Delivery Time :

According to the quantiy and stocking , 3-4 working days after payment

Payment Terms :

T/T , Western Union

Supply Ability :

According to the different products , the monthly output is different

Price :

depends on the quantity

SDI Standard :

HD-SDI, SD-SDI

Data Rates :

270Mbps/1.485 Gbps/2.97Gbps

Signal Type :

SMPTE 292M, SMPTE 259M,SMPTE424M

Power Supply :

DC 5-24V

size :

80*61*28mm

Description

HD-SDI Distribution Amplifier 1 x 2 SD/HD -SDI Repeaters

Newbridge® ND1102BD SD HD-SDI 1:2 Repeater& Distribution Amplifier is a 1 to 2 repeater and distribution amplifier with Re-clocking function It receive one SDI input and perfectly duplicates it Then it re-transmits two SDI outputs for real time multi-viewing It is a reliable video device splitting a SDI or HD-SDI video source to two HD-SDI or SD-SDI display at the same time and takes one input then re-clocks and equalizes the signal and distributes it to two identical outputs

Feature

◆SDI Standard: HD-SDI, SD-SDI
◆Data Rates: 270Mbps/1.485 GbpsSignal Type: SMPTE 292M, SMPTE 259M
◆Two separately buffered outputs
◆Cable equalization (Beldon 1694A) retiming and signalRe-clocking function capability – unlimited repeater connection
◆With LED indication of input lock and rate
◆Pass all ancillary data
◆5V~12V DC

Specification

Model	ND1102BD HD-SDE-122R
Re-clocking Function	Yes
SDI Standards	SD-SDI, HD-SDI
HD/SD-SDI Detection	Auto
Supported Protocols	SMPTE 259M SMPTE 292M SMPTE 344M
Data Rates	270 / 1483 / 1485 Mbps
V ideo Support	SD: 525i @ 59.94Hz, 625i @ 50Hz HD: 720p @ 23.98/24Hz/25Hz/29.97Hz/30Hz/50Hz / 59.94Hz / 60Hz 1080i @ 50Hz / 59.94Hz / 60Hz 1080p @23.98Hz/24Hz/25Hz/29.97Hz/30Hz
SDI Signal Type	SMPTE-292M, SMPTE-259M
Output Impedance	75 ohms
Max. Distance	Belden 1694A SD-SDI 400m / 1300ft ; HD-SDI 200m / 600ft
Audio Support	Yes
Input	1x BNC [SDI]
Output	2x BNC [SDI]
BNC Connector	75 ohms inter-locked socket
Power Consumption	2~4 Watts
Relative Humidity	20~90% RH (no condensation)
Dimension	806128mm
Weight	120g

Connection diagram

Order information

Part No	Description of product	Unit
ND1120BD	1X2 SD/HD -SDI Repeaters	pcs

HD-SDI Distribution Amplifier 1 x 2 SD/HD -SDI Repeaters

Product tags

Send your message to this supplier

Message*

Email*

Phone or WhatsApp*

Name

Company

Please reply me within 24 hours.

Yes! I would like your verified suppliers matching service!

Send Now

Submission successful!

HD-SDI Distribution Amplifier 1 x 2 SD/HD -SDI Repeaters

Name: HDSDI Distribution Amplifier 1 x 2 SDHD SDI Repeaters
Brand: NEWBRIDGE
Price: 1 USD

Ask Latest Price

Product Detail

Brand Name :

NEWBRIDGE

Model Number :

ND1102BD

Certification :

CE,FCC

Place of Origin :

SHENZHEN,CHINA

MOQ :

1PC

Packaging Details :

packing can be done by customer's requested, usually used in carton

Contact Supplier

Shenzhen Newbridge Communication Equipment Co.,Ltd

Active Member

8 Years

guangdong, shenzhen

Since 2004

Business Type :

Manufacturer, Exporter

Main Products :

10 100M Media Converter, Rack Mount Media Converter, 10 100 1000M Media Converter

Certification Level :

Active Member

Discover similar products

1x8 HD SDI Distribution Amplifier Support Re-Clocking

Contact Now
2 to 4 HD SDI Distribution Amplifier with Video Signal Distribution Amplifier

Contact Now
HD-SDI Distribution Amplifier 1x2 port 3G/HD-SDI Distribution Amplifier Splitter

Contact Now
HD SDI Distribution Amplifier SD SDI 1 To 4 Distribution Amplifier

Contact Now
HD-SDI Distribution Amplifier SD/HD/3G-SDI 1 to 4 Distribution Amplifier
