AC 220V CE Certification HD SDI Converter 1550nm Support 8 Channel Video
AC 220V CE Certification HD SDI Converter 1550nm Support 8 Channel Video
Specifications
Brand Name :
NEWBRIDGE
Model Number :
ND-8018D
Certification :
CE,FCC
Place of Origin :
SHENZHEN,CHINA
MOQ :
1PC
Price :
Negotiation
Packaging Details :
packing can be done by customer's requested, usually used in carton
Delivery Time :
According to the quantiy and stocking , 3-4 working days after payment
Payment Terms :
T/T , Western Union
Supply Ability :
According to the different products , the monthly output is different
size :
480*162*43mm
Power Supply :
AC110V/220V
type :
single mode，single fiber
Storage Temperature :
Storage Temperature
Power Consumption :
3-5 Watts
port :
8 BNC SD/HD-SDI
Description

AC 220V CE Certification HD SDI Converter 1550nm Support 8 Channel Video

Newbridge® ND8014D SD HD-SDI series Optical Transceivers are a group of perfect and economic transmission device to transmit 4CH 8CH SD HD-SDI video to up to further distance by one fiber cable, embedded audio and RS485 data via fiber-optic Transmitter is used as sending and Receiver is used as receiving System support in accordance with SMPTE292M, SMPTE259M standard, as well as DVB-ASI (EN50083-9) digital TV signal format


Feature

◆Support 4/8 channel SD/HD/3G-SDI video embedded audio signal via fiber

◆SD,HD auto-detection, supported transmission rate from 270M bit/s to 1.485G bit/s

◆Transmission distance is from 0km to 60KM via multimode fiber or single mode fiber.

◆Support SMPTE 259M (1.485Gbps),SMPTE 259M (270Mbps) and DVB-ASI

◆With 2CH Bi-Di data

◆Operation status indication by LED

Specification

Model/Name ND8104D ND8108D
Quantity/Type Single Mode, Single Fiber
Video port 4CH BNC SD/HD-SDI 8CH BNC SD/HD-SDI
Transmission Distance 0m-20Km/40km/60KM optional
Fiber Connector FC
Wave Length 1310nm/1550nm
Transmitted power -10dbm～-3dbm
<-34dbm
Maximum Receiving Sensitivity <-34dbm
Signal Type SD-SDI(270Mbps)/HD-SDI(1.485Gbps)
Support Input Format SD: 525i @ 59.94Hz, 625i @ 50Hz
HD: 720p @ 25Hz / 29.97Hz / 30Hz
720p @ 50Hz / 59.94Hz / 60Hz
1080i @ 50Hz / 59.94Hz / 60Hz
1080p @23.98Hz/24Hz/25Hz/29Hz/30Hz
Video Standard SMPTE 292M , SMPTE 259M
DATA comm. method 2CH RS-485/Half duplex/ Industrial terminals
In-out electrical level 800mVp-p±10%
In-0ut Ohm 75Ohm
Digital Audio 48KHz
AES digital audio channel 8CH
Power Supply AC110V/220V
Power Consumption 3~5 Watts
Operating Temperature 0°C ~ 60°C / 32°F ~ 140°F
Storage Temperature -30°C ~ 70°C / -22°F ~158°F
Relative Humidity 20~90% RH (Non-condensation)
Dimension 480*162*43mm/18.9*6.38*1.69in
Weight 2880g(Tx and Rx) 2950g(Tx and Rx)

Connection diagram

AC 220V CE Certification HD SDI Converter 1550nm Support 8 Channel Video

Order information

Part No Description of product Unit
ND8018D-Tx SD/HD-SDI Optical-Transmitter pcs
ND8018D-Rx SD/HD-SDI Optical-Receiver pcs
