Specifications
Brand Name :
NEWBRIDGE
Model Number :
ND-820SW-S20-2
Certification :
FCC,CE
Place of Origin :
SHENZHEN,CHINA
MOQ :
1PC
Price :
Negotiation
Packaging Details :
packing can be done by customer's requested, usually used in carton
Delivery Time :
According to the quantiy and stocking , 3-4 working days after payment
Payment Terms :
T/T , Western Union
Supply Ability :
5000PCS per month
Optical Port :
SC
Working Temperature :
0-50℃
Humidity :
5-90 %( non-condensing)
power supply :
External, AC 100V-260V, DC 5V 1A
Size :
133*85*26 mm
Ethernet Port :
one RJ45
Description

1 fiber port 2 rj45 10/100Mbps media converter best buy ethernet fiber media converter

Fiber media converter, or fiber converter, media converter, or Ethernet fiber converter, is designed to extend the copper limit of 100 meters and gets Ethernet connected to 120km max on fiber optics Fiber media converter is a simple networking device that connects two dissimilar media types such as copper twisted pair and fiber optics

Feature

1. 100BASE-FX FIBER to 10/100BASE-T COPPER Ethernet conversion
2. Auto-MDI/MDIX copper RJ45 port
3. 1600byte super data packet transmission
4. Full duplex-flow control, half duplex-back pressure
5. Link fault pass through (LFPT)
6. Full- positioned LEDs to indicate power and network status

specification

Standard IEEE802.3 (10BASE-T),IEEE802.3u 100BASE-TX/FX (Fast-Ethernet),IEEE802.3x (Flow Control),IEEE802.1q, IEEE802.1p QoS, IEEE802.1d Spanning Tree
10/10 0 BASE-T STP or UTP Category 5/5e/6 cable (Max. 100m)
100BASE-FX 50/125umfiber cable (5km), 62.5/125um multimode fiber cable (2km)
9/125um singlemode fiber cable (20/40/60/80/100km)
Conversion M ode / D elay T ime Store-and-Forward < 10us, straight-through<0.9us
Flow control Full duplex-flow control, Half duplex-back pressure
RJ-45 Port Auto-MDI/MDIX
Fiber Connector SC standard, ST/FC optional
Wavelength 1310/1550nm
Dimensions 130mm X 86 mm X 26mm
Weight Net weight : 0.16kg; Gross weight : 0.42kg
Input Voltage DC 5V1A with External power adapter
Power Consumption <2.5W
MTBF 50,000 hours
BER <1/1000000000
MAC Address Table 1K
Buffer Size 1M
Operating Temperature 0°C~50°C
Storage Temperature -40°C~70°C
Storage Humidity 5%~90% non-condescending

Order info

Order info

Part No Description of product Unit
ND-820SW-S20-2 10M/100M bps, Single mode,1310nm,0-20KM,SC 1pc
