100% Compatible 10G SFP+ Transceiver Dual Fiber LC Connector 1310nm 20Km 10G-SFP-LR
100% Compatible 10G SFP+ Transceiver Dual Fiber LC Connector 1310nm 20Km 10G-SFP-LR
100% Compatible 10G SFP+ Transceiver Dual Fiber LC Connector 1310nm 20Km 10G-SFP-LR
100% Compatible 10G SFP+ Transceiver Dual Fiber LC Connector 1310nm 20Km 10G-SFP-LR
Specifications
Brand Name :
HILINK
Model Number :
HL-SFP-10G-LR
Certification :
CE FCC Rohs
Place of Origin :
Guangdong, China
MOQ :
1pcs
Price :
Get latest price
Payment Terms :
T/T, Western Union, MoneyGram,Paypal
Supply Ability :
5000pcs/Month
Delivery Time :
2-5working days
Packaging Details :
Static bag, Plastic Flat, Retail box, by requires
Product name :
10G-SFP-LR
Data Rate :
10G
Wavelength :
1310nm
Distance :
20Km
DDM :
Yes
Connector type :
LC
Warranty :
3 years
CE,RoHS :
Compliant
Description

100% Compatible 10Gbps SFP+ Dual Fiber LC Connector 1310nm 20Km 10G-SFP-LR

Feature

  • Duplex LC Connector
  • Support hot-pluggable
  • Metal with lower EMI
  • Excellent ESD protection
  • DFB Transmitter and PIN Receiver
  • Typical Center Wavelength:1310nm
  • Max link length up to 10Km on SMF
  • RoHS Compliant and Lead-Free
  • Digital diagnostic compatible with SFF-8472
  • Case Operation Temperature:-5℃~+70℃
  • Single 3.3V power supply and Low power

Application

  • 10GBASE-LR/LW 10G Ethernet
  • Performance Specifications
  • Absolute maximum rating
  • Exceeding the limits below may damage the transceiver module permanently. ​

Description

SFP+ LR is specifically designed for the high performance integrated duplex data transmission over single mode optical fiber. This transceiver module is compliant with the Small Form-factor Pluggable Plus (SFP+) Multisource Agreement (SFF-8431 Rev4.1).This transceiver type is specifically optimized for transport of serial data at up to 10.3125 Gbps, with link characteristics complied with 10-Gigabit Ethernet 10GBASE-LR base IEEE 802.3ae and 10G Fibre Channel 1200-SM-LL-L. 5

Parameter

Datarate 10Gbps Fiber Type SMF
Transmitter DFB Receiver PIN
Distance 20Km Wavelenth 1310nm
DDM/DOM Yes Connector LC
Voltage Supply 3.3V Compatibility Cisco/Huawei/Mikrotik etc
Operating Temperature 0℃~ +70℃ Certification CE/FCC/RoHS

SFP+ Transceivers

Cisco Part Number Application Data Rate Wavelength Distance

Connector

Type

SFP-10G-SR SFP+ 10GBASE-SR 10G 850nm 300m LC
SFP-10G-LR SFP+ 10GBASE-LR 10G 1310nm 10km LC
SFP-10G-LRM SFP+ 10GBASE-LRM 10G 1310nm 220m LC
SFP-10G-ER SFP+ 10GBASE-ER 10G 1550nm 40km LC
SFP-10G-ZR SFP+ 10GBASE-ER 10G 1550nm 80km LC

100% Compatible 10G SFP+ Transceiver Dual Fiber LC Connector 1310nm 20Km 10G-SFP-LR
