0.9mm, 2.0mm, 3.0mm all type fiber optic lemo connector
0.9mm, 2.0mm, 3.0mm all type fiber optic lemo connector
0.9mm, 2.0mm, 3.0mm all type fiber optic lemo connector
0.9mm, 2.0mm, 3.0mm all type fiber optic lemo connector
0.9mm, 2.0mm, 3.0mm all type fiber optic lemo connector
0.9mm, 2.0mm, 3.0mm all type fiber optic lemo connector
0.9mm, 2.0mm, 3.0mm all type fiber optic lemo connector
0.9mm, 2.0mm, 3.0mm all type fiber optic lemo connector
0.9mm, 2.0mm, 3.0mm all type fiber optic lemo connector
0.9mm, 2.0mm, 3.0mm all type fiber optic lemo connector
Specifications
Place of Origin :
Guangdong, China
Brand Name :
HYG
Model Number :
HYG-FACT-fc/sc/st/lc
ferrule type :
APC/upc/pc
connector typ :
SC/st/fc
data transmission :
CATV
optical fiber sensors :
single mode
APC polishing :
APC polishing
security & protection :
fiber parts & Accessories
Telecommunication :
power supply & distrubution
ferrule :
ceramic ferrule
Type :
embedded type
Supply Ability :
1000000 Piece/Pieces per Month
Packaging Details :
2000 pcs/ctn,34*33*68cm
Port :
shenzhen
MOQ :
50 Piece/Pieces
Price :
$1.20 - $1.50 / Piece
Description

0.9mm, 2.0mm, 3.0mm all type fiber optic lemo connector

The Optical Field Assembly Connectors Precision metallic V-Groove components with co-axial self centering, excellent and durable fixing property. The structure base on unique box-building crimping technology. Preseting the Bending fiber prevent the cable from draging. Integrated protection of the casing to withstand harsh indoor environment. After terminating, both the optical and mechanical performance reach the standard for FTTH.

Characteristics:

Good performance and High success rate.

Easiness in installation with average splicing time of 15 sec

Special tool is simple and convenient to use.

Reusable and repeat orperation times are up to 100.

Integrated protection of the casing to prevent the connector form impact

On line tension is up to 20N to protect the connector from the draging

The maxmum tension is up to 100N. It’s the most safety connector

Application:

FTTX/FTTH fiber to the home

Local area network and smart grid

Mining and Oil

Security equipment

Optical Characteristics:

Items G.652G.657Asuper soft fiber
Insert loss@1310 nm/≤ 0.3dB≤ 0.25 dB
@1550 nm/≤ 0.35 dB≤ 0.3 dB
Return loss@1310 nm/≤ -40 dB≤ -45 dB
@1550 nm/≤ -40 dB≤ -45 dB

Environment Parameters

Test ItemChange ILChange RLTest condition
Mechanical life≤ 0.2 dB≤ 5 dB500 (times)300/100010D/20D
On line tension≤ 0.2 dB≤ 5 dB20N300/100010D/20D
Impation≤ 0.2 dB≤ 5 dB 4m high / 3 axis/ 3times300/100010D/20D
High temperature storage≤ 0.2 dB≤ 5 dB80C / 96(hours)300/100010D/20D
Low temperature storage≤ 0.2 dB≤ 5 dB-40C / 96(hours)
Temperature cycling≤ 0.2 dB≤ 5 dB-40C – 75C / 96(hours)

Storage/Operating Temperature: -40°C to +70°C

0.9mm, 2.0mm, 3.0mm all type fiber optic lemo connector

Pls feel free contact with me if you like the items .My skype: sophiahyg.
