SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF
SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF
SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF
SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF
SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF
SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF
SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF
SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF
SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF
SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF
SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF
SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF
Specifications
Brand Name :
Cisco
Model Number :
SFP-10G-ZR
Certification :
CE
Place of Origin :
China
Model :
SFP-10G-ZR
Transceiver form factor :
SFP+
Connector Type :
LC
Wavelength :
1550nm
Cable Distance :
40km
Data Rate :
10 Gbps
Condition :
Brand New Sealed
Warranty :
1 year
Payment :
T/T, Western Union, Paypal
Shipment :
DHL, Fedex, UPS
Description

Cisco SFP-10G-ZR Overview

The Cisco SFP-10G-ZR is a multi-rate 10GBASE-ZR, 10GBASE-ZW, and OTU2/OTU2e module. It supports link lengths of up to about 80 kilometers on standard Single-Mode Fiber (SMF, G.652). This interface is not specified as part of the 10 Gigabit Ethernet standard and is instead built according to Cisco specifications.

SFP-10G-ZR SFP-10G-ZR - Cisco 10GBASE-ZR SFP10G Module For SMF Cisco 10GBASE-ZR SFP10G Module For SMF

Quick Spec

Table 1 shows the quick spec.

Model Cisco SFP-10G-ZR*
Wavelength (nm) 1550
Cable Type SMF
Core Size (Microns) G.652
Modal Bandwidth (MHz*km) ** -
Cable Distance*** 80km

*Requires 15dB attenuator if Link Distance < 5km.

Requires 10dB attenuator if Link Distance is between 5km and 15km.

Requires 5dB attenuator if Link Distance is between 15km and 25km.

**Specified at transmission wavelength.

***Minimum cabling distance for -SR, -LRM, -LR, -ER modules is 2m, according to the IEEE 802.3ae.

Platform support

Table 2 shows the recommend series of platforms.

● 7600 Series Router

● ASR-903

● ASR 1000 Series Router

● ASR 9000 Series Router

● Catalyst 2960-S, 2960-X, and 2960-XR Series Switches

● Catalyst 3850 Series Switches

● Catalyst 4500 and 4500-X Series Switches

● Nexus 2000, 3000 Series Switches

● Nexus 9000 and 9500 (modular) Series Switches

Compare to Similar Item

Table 3 shows the comparison.

Cisco SFP+ Wavelength (nm) Cable Type Core Size (Microns) Modal Bandwidth (MHz*km) Cable Distance
Cisco SFP-10G-SR 850 MMF 62.5 160 (FDDI) 26m
62.5 200 (OM1) 33m
Cisco SFP-10G-SR-X 50 400 66m
50 500 (OM2) 82m
50 2000 (OM3) 300m
50 4700 (OM4) 400m
Cisco SFP-10G-LRM 1310 MMF 62.5 500 220m
SMF 50 400 100m
50 500 220m
G.652 - 300m
Cisco SFP-10G-LR 1310 SMF G.652 - 10km
Cisco SFP-10G-ER 1550 SMF G.652 - 40km
Cisco SFP-10G-ZR 1550 SMF G.652 - 80km

Cisco SFP-10G-ZR Specification

Cisco SFP-10G-ZR Specification
SFP+ port cabling specifications
Wavelength (nm) 1550
Cable Type SMF
Core Size (Microns) G.652
Modal Bandwidth (MHz*km) -
Cable Distance 80km
Optical transmit and receive specifications
Type 10GBASE-ZR 1550nm SMF
Transmit Power (dBm) 4.0 (Max), 0 (Min)
Receive Power (dBm) -7 (Max), -24 (Min)
Transmit and Receive Wavelength (nm) 1530 to 1565
Other Specification
Bail Latch Color Green
Power Consumption (W) 1.5
Operating Temperature Range COM
Dimensions

Dimensions (H x W x D): 8.5 x 13.4 x 56.5mm.

Cisco SFP+ connectors typically weigh 75 grams or less.
Operating Temperature Range

● Commercial temperature range (COM): 0 to 70°C (32 to 158°F)

● Extended temperature range (EXT): -5 to 85°C (23 to 185°F)

● Industrial temperature range (IND): -40 to 85°C (-40 to 185°F)

● Storage temperature range: -40 to 85°C (-40 to 185°F)
