Huawei USG6300 Next Generation Firewall 4GE RJ45 2GE Combo 4GB Memory 1 AC Power USG6330-AC
Huawei USG6300 Next Generation Firewall 4GE RJ45 2GE Combo 4GB Memory 1 AC Power USG6330-AC
Huawei USG6300 Next Generation Firewall 4GE RJ45 2GE Combo 4GB Memory 1 AC Power USG6330-AC
Huawei USG6300 Next Generation Firewall 4GE RJ45 2GE Combo 4GB Memory 1 AC Power USG6330-AC
Specifications
Brand Name :
Huawei
Model Number :
USG6330-AC
Certification :
CE
Place of Origin :
China
MOQ :
1 PC
Price :
Negotiable
Payment Terms :
Western Union, Paypal,T/T
Supply Ability :
1000 Pcs /Month
Delivery Time :
1~2 days
Packaging Details :
New in box
Brand :
Huawei
Attributes :
Hardware
Product Family :
Firewall
Product Code :
USG6330-AC
Description

Huawei USG6300 Next-Generation Firewall USG6330-AC 4GE(RJ45)+2GE Combo,4GB Memory,1 AC Power)​

The USG6330-AC is a unified security gateway designed for enterprise network environments. It provides a comprehensive set of security and network management features. Here are some key features and specifications:

Key Features

  • Firewall: Offers advanced firewall capabilities, including stateful packet inspection and intrusion prevention systems (IPS).
  • VPN Support: Supports various VPN protocols (such as IPsec and SSL) for secure remote access.
  • Traffic Management: Provides Quality of Service (QoS) features to optimize bandwidth usage and manage traffic effectively.
  • Threat Protection: Includes features for malware detection, content filtering, and anti-spam to enhance network security.
  • High Availability: Supports clustering and redundancy to ensure continuous network operation.

Specifications

  • Performance: Capable of handling high throughput, making it suitable for medium to large enterprises.
  • Ports: Typically includes multiple Gigabit Ethernet ports for LAN and WAN connectivity.
  • Management: Offers a web-based management interface, CLI, and integration with centralized management solutions.

Use Cases

  • Enterprise Networks: Ideal for securing internal networks and providing safe remote access for employees.
  • Branch Offices: Suitable for distributed network environments, ensuring consistent security policies across locations.

USG6330-AC Overview

The Huawei USG6330-AC next-generation firewall provides comprehensive protection in small- to medium-sized enterprise networks, ideal solution for branch locations. It provides fine-grained service access control and service acceleration through context awareness by Application, Content, Time, User, Attack, or Location (ACTUAL).

Dimensions (H x W x D) 44.4 mm x 442 mm x 421 mm
Form Factor/Height 1U
Fixed Interfaces 4 x GE (RJ45) + 2 x GE (Combo)
USB 2.0 Port Supported
Expansion Slot 2WSIC*
Expansion I/O WSIC: 2 x 10 GE (SFP+) + 8 x GE (RJ45), 8 x GE (RJ45), 8 x GE (SFP), and 4 x GE (RJ45) BYPASS
Maximum Number of Interfaces 22 x GE (RJ45) + 4 x 10 GE (SFP+) or 18 x GE (SFP) + 4 x GE (RJ45)
MTBF 11.58 years
Weight (full configuration) 7.9 kg
Local Storage Optional. Supports a 300 GB or 600 GB hard disk (the hard disk is hot-swappable, but the hard disk card is not)
AC Power Supply 100V to 240V, 50 Hz/60 Hz
Power Consumption (average/maximum) 30.7W/107.83W
Heat Dissipation 368 BTU/h
Power Supplies Single 150W AC power supply; optional 170W AC power supply
Operating Environment (temperature/humidity) Temperature: 0°C to 45°C (without optional HDD)
5°C to 40°C (with optional HDD)
Humidity: 5% to 95% (without optional HDD), non-condensing
5% to 90% (with optional HDD), non-condensing
Non-operating Environment Temperature: -40°C to 70°C
Humidity: 5% to 95% (without optional HDD), non-condensing;
5% to 90% (with optional HDD), non-condensing
Operating Altitude (maximum) 5,000 meters (without optional HDD); 3,000 meters (with optional HDD)
Non-operating Altitude (maximum) 5,000 meters (without optional HDD); 3,000 meters (with optional HDD)
Noise 54.1 dBA

Huawei USG6300 Next Generation Firewall 4GE RJ45 2GE Combo 4GB Memory 1 AC Power USG6330-AC

USG6330-AC Specification

Quick Specs

Figure 1 shows the appearance of Huawei USG6330-AC firewall.

Table 1 shows the Quick Specs.

Product Code USG6330-AC
Mandatory service ports

2 x GE Combo ports,

4 x 10/100/1000M autosensing Ethernet electrical ports

IPv4 Firewall Throughput

(1518/512/64-byte, UDP)

 1/1/0.4 Gbit/s

IPv6 Firewall Throughput

(1518/512/84-byte, UDP)

 1/1/0.5 Gbit/s

Firewall Throughput

(Packets Per Second)

 0.6 Mpps
AC Power Supply 100V to 240V
Height 1 U
Dimensions (W x D x H) 442 mm × 421 mm × 44.4 mm
Weight 8.7 Kg

Product Details

Table 2 shows the front panel of Huawei USG6330-AC firewall.

① ESD Jack ⑤ 4 x GE (RJ45) + 2 x GE (Combo)
② RST Button ⑥ 2 x Expansion Slots
③ One USB 2.0 Ports ⑦ One Out-of-band Management Port
④ One Console Port ⑧ Slot Numbering Layout and Indicator Area

Table 3 shows the back panel of Huawei USG6330-AC firewall.

This is a Schematic diagram for reference, not a real product.

Note:

① Hard Drive Assembly (Optional)
② Power Module
③ Slot for Optional Power Module

The Modules, Cards, Licenses

Table 2 shows the recommended elements for the Huawei USG6330- AC firewall.

Category Model Description
Business Module Group WSIC-8GE Huawei SVN5800 Secure Access Gateways 8GE Electric Ports Interface Card
WSIC-2XG8GE Huawei 2*10GE Optical Ports+8GE Electric Ports Interface Card for USG6300 Next-Generation Firewall.
Hard disk Group SM-HDD-SAS300G-B Huawei 300GB 10K RPM SAS Hard Disk for 1U rack Gateway
Option Power Group Power-AC-B Huawei Power-AC-B 170W AC power module

Optical Transmitter

Module Collection

 SFP-GE-LX-SM1310 Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,10km,LC)
S-SFP-GE-LH40-SM1310 Huawei AR G3 Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,40km,LC)
eSFP-GE-SX-MM850 Optical Transceiver, eSFP, GE, Multi-mode Module 850nm,0.5km,LC
Function License LIC-VSYS-10-USG6000 Huawei Quantity of Virtual Firewall (10 Vsys) Software/License
LIC-SSL-100-USG6000 Huawei Software/License: Quantity of SSL VPN Concurrent Users License (100 Users)
NGFW License LIC-IPS-12-USG6300-02 Huawei IPS Update Service Subscribe for 12 Months (Applies to USG6330/50/60) license.
LIC-URL-12-USG6300-02 Huawei URL Filtering Update Service Subscribe for 12 Months (Applies to USG6330/50/60) license.
LIC-AV-12-USG6300-02 Huawei Anti-Virus Update Service Subscribe for 12 Months (Applies to USG6330/50/60) license.
Basic License LIC-CONTENT Huawei Content Filtering Function Software/License

Compare to Similar Items

Table 3 shows the comparison of Huawei USG6330-AC and USG6350 -AC firewalls.

Models USG6330-AC USG6350-AC
Mandatory service ports

2 x GE Combo ports,

4 x 10/100/1000M autosensing Ethernet electrical ports

2 x GE Combo ports,

4 x 10/100/1000M autosensing Ethernet electrical ports
Expansion slot 2 × WSIC 2 × WSIC

IPv4 Firewall Throughput

(1518/512/64-byte, UDP)

 1/1/0.4 Gbit/s 2/2/0.4 Gbit/s

IPv6 Firewall Throughput

(1518/512/84-byte, UDP)

 1/1/0.5 Gbit/s 2/2/0.5 Gbit/s

Firewall Throughput

(Packets Per Second)

 0.6 Mpps 0.6 Mpps


Business

Huawei USG6300 Next Generation Firewall 4GE RJ45 2GE Combo 4GB Memory 1 AC Power USG6330-AC Huawei USG6300 Next Generation Firewall 4GE RJ45 2GE Combo 4GB Memory 1 AC Power USG6330-AC Huawei USG6300 Next Generation Firewall 4GE RJ45 2GE Combo 4GB Memory 1 AC Power USG6330-AC
