Specifications
Brand Name :
Huawei
Model Number :
CE6863E-48S6CQ-B
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Price :
US$1984/PC
Payment Terms :
L/C, T/T
Model :
CE6863E-48S6CQ-B
Name :
CE6863E-48S6CQ-B Switch Huawei 24 Port Ethernet Switches Uplink Ports
Chassis height [U :
7
Power supply mode :
AC built-in
Memory :
512 MB
Flash memory :
512 MB
USB :
Supported
Types of fans :
Built-in
Description

CE6863E-48S6CQ-B Overview

Built on next-generation, high-performance hardware and powered by Huawei’s Versatile Routing Platform (VRP), CloudEngine CE6863E switches feature flexible Ethernet networking, diversified security control, and support for multiple Layer 3 routing protocols — providing higher performance and more powerful service processing capabilities for networks.

Item Details
Description CE6863E-48S6CQ switch (48*25GE SFP28, 6*100GE QSFP28)
Part Number 02354GCT
Model CE6863E-48S6CQ
First supported version V200R021C00
Other part numbers

02354GCW (CE6863E-48S6CQ-B switch (48*25GE SFP28, 6*100GE QSFP28, 2*AC power modules, 4*fan modules, port-side intake))

02354GCX (CE6863E-48S6CQ-F switch (48*25GE SFP28, 6*100GE QSFP28, 2*AC power modules, 4*fan modules, port-side exhaust))
Short Name CE6863E
Item Specification
Dimensions with packaging (H x W x D) [mm (in.)] 175 mm x 650 mm x 550 mm (6.9 in. x 25.6 in. x 21.7 in.)
Dimensions without packaging (H x W x D) [mm (in.)]
  • Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.40 in. x 16.54 in.)
  • Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 446.1 mm (1.72 in. x 17.40 in. x 17.56 in.)
Weight without packaging (base configuration) [kg (lb)] 5.7 kg (excluding optical modules, power modules, and fan modules)
Weight without packaging (full configuration) [kg (lb)] 7.8 kg (17.2 lb) (including AC power modules and fan modules, excluding optical modules, calculated based on the heaviest model if multiple models are supported)
Weight with packaging (base configuration) [kg (lb)] 8.95 kg
Weight with packaging (full configuration) [kg (lb)] 11.05kg
Installation Type Cabinet Installation
CPU 4-core, 1.4GHZ
Memory DRAM: 4 GB
NOR Flash 64 MB
NAND Flash 4 GB
USB Supported
Power supply mode
  • AC
  • DC
  • HVDC
Console port RJ45
Downlink Service interface 48*25GE SFP28 (Note: 1. 25GE ports can be configured to work at 10 Gbit/s or 1 Gbit/s. Every four downlink 25GE ports form a group, and can be configured to work at 10 Gbit/s or 1 Gbit/s through the command; 2. 10GE LRM/80KM linear optical modules are not supported; 3. 1 m 25GE copper cables and 1 m/3 m/5 m 10GE copper cables are supported, and auto-negotiation of copper cables is not supported; 4. 25GE copper cables can only be used on stack ports and M-LAG peer-link ports.)
Uplink Service interface 6*100GE QSFP28 (Note: 1. Each 100G QSFP28 port can be configured to work at 40 Gbit/s. 2. A 100G QSFP28 port cannot be split into four 25GE or 10GE ports. 3. 100GE and 40GE 1/3/5 m copper cables are supported, but auto-negotiation of copper cables is not supported. 100GE and 40GE copper cables can only be used on stack interfaces and M-LAG peer-link interfaces. 100G 3/5 m copper cables support only RS FEC. After the non-RS FEC mode is configured, the port enters the error-down state.)
Service port supporting the stack function 25GE optical ports, and 100GE optical ports
RTC Supported
Typical power consumption [W]

226 W (100% throughput, SFP28 high-speed cables on 48 ports and QSFP28 high-speed cables on 6 ports, dual power modules)

261 W (100% throughput, short-distance optical modules on all ports, dual power modules)
Typical heat dissipation [BTU/hour]

771 BTU/hr (100% throughput, SFP28 high-speed cables on 48 ports and QSFP28 high-speed cables on 6 ports, dual power modules)

891 BTU/hr (100% throughput, short-distance optical modules on all ports, dual power modules)
Static power consumption [W] 167 W
Static heat dissipation [BTU/hour] 570 BTU/hour
Maximum power consumption [W] 384 W
Maximum heat dissipation 1310 BTU/hour
Number of power modules 2
Redundant power supply 1+1 backup
Rated input voltage [V]

Rated AC input voltage range: 100 V AC to 240 V AC; 50/60 Hz

Rated –48 V DC input voltage range: –48 V DC to –60 V DC

Rated input voltage range for 600 W AC & 240 V DC: 240 V DC

Rated input voltage range for 1200 W HVDC: 240 V DC to 380 V DC
Input voltage range [V]

Maximum AC input voltage range: 90 V AC to 290 V AC; 45 Hz to 65 Hz

Maximum –48 V DC input voltage range: –38.4 V DC to –72 V DC

Maximum input voltage range for 600 W AC & 240 V DC: 190 V DC to 290 V DC

Maximum input voltage range for 1200 W HVDC: 190 V DC to 400 V DC
Maximum input current [A]

600 W AC&240 V DC power module (PAC600S12 series):

· 8 A (100 V AC to 240 V DC)

· 4 A (240 V DC)

1000 W DC power module (PDC1000S12 series): 30 A (–48 V DC to –60 V DC)

1200 W high-voltage DC power module (PHD1K2S12 series): 8 A
Rated output power [W]

600 W (AC&240 V HVDC)

1000 W (–48 V DC)

1200 W (380 V HVDC)
Certification

· Complies with safety standards.

· Complies with EMC standards.

· Complies with environmental protection standards.
Power supply surge protection [kV]

AC: 6 kV in common mode and 6 kV in differential mode

DC: 4 kV in common mode and 2 kV in differential mode

HVDC: 4 kV in common mode and 2 kV in differential mode
Types of fans Pluggable
Number of fans 4
Redundant fans The device supports 3+1 backup of fan modules that work in hot standby mode. The system can operate properly for a short time after a single fan module fails. You are advised to replace the faulty fan module immediately.
Heat dissipation mode Air cooling
Airflow direction Front-to-back or back-to-front, depending on the fan modules and power modules.
Availability 0.9999962836
MTBF [year] 47.81 years
MTTR [hour] 1.95 hours
Noise at normal temperature (27°C, sound pressure) [dB(A)]
  • Front-to-back airflow: < 58 dB(A)
  • Back-to-front airflow: < 57 dB(A)
Noise at high temperature (40°C, sound pressure) [dB(A)]
  • Front-to-back airflow: < 75 dB(A)
  • Back-to-front airflow: < 74 dB(A)
Long-term operating altitude [m (ft.)] ≤ 5000 m (16404 ft.)
Long-term operating relative humidity [RH] 5% RH to 95% RH, noncondensing
Long-term operating temperature [°C (°F)]

0°C to 40°C (32°F to 104°F) at an altitude of 0–1800 m (0–5906 ft.)

NOTE:

When the altitude is 1800–5000 m (5096–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
Storage altitude [m (ft.)] ≤ 5000 m (16404 ft.)
Storage relative humidity [RH] 5% RH to 95% RH, noncondensing
Storage temperature [°C (°F)] –40°C to +70°C (–40°F to +158°F)
