LC UPC 12 Core Bundled Optic Fiber Patch Cord
LC UPC 12 Core Bundled Optic Fiber Patch Cord
LC UPC 12 Core Bundled Optic Fiber Patch Cord
LC UPC 12 Core Bundled Optic Fiber Patch Cord
Specifications
Brand Name :
KNOFC or OEM
Model Number :
Pigtail LC/UPC
Certification :
CE/ISO9001
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
20000/week
Packaging Details :
bag
Fiber type :
Single mode 9/125
Connector type :
LC/UPC
Length :
1M or Customized
Cable color :
White or Yellow
Cable diameter :
0.9mm
Insertion loss :
≤0.3dB
Operating Temperature :
-20°C to+50°C
Description

Optical Pigtail LC UPC 12 Core Bundled Optic Fiber Patch Cord​

Description:

The optical Fiber Connectors (Commonly we call Patch Cords) is a length of optical cable with connectors fixed on one ends to realize the optical path active connection. Pigtail is a length fiber cable with only one connector fixed on one end. According to the transmission medium, it divides Single Mode and Multi Mode; according to the connector structure type, it divides FC, SC, ST, MU, D4, E2000,LC etc.; according to the polished ceramic end-face, it divides PC, UPC and APC.

Features:
1. Type FC Fiber Optic Patchcord and Pigtail
2. Single mode and Multimode PC or 8 degree APC 9 degree APC
3. Cable 0.9mm, 2.0mm, 2.4mm or 3.0mm with simplex or duplex and 4,6,8,12,24,48 Core
4. Customized length
5. Cable color green, yellow, orange or Customized Designs
6. Cable PVC,Hytrel,LSZH,OFNP,OFNR
7. All parts compliant with ROHS
8. IEC standard compatible
9. All parts compliant with ROHS
10. GR-326-CORE Compliant

Specification:

Parameter Unit Mode Type PC UPC APC
Insertion Loss dB SM ≤0.3 ≤0.3 ≤0.3
Insertion Loss dB MM ≤0.3 ≤0.3 -----
Return Loss dB SM ≥50 ≥50 ≥60
Return Loss dB MM ≥35 ≥35 -----
Fiber cable Material PVC, LSZH
Fiber cable Diameter 0.9mm, 2.0mm, 3.0mm
Connector type SC, LC. ST. FC
Repeatability dB Additional loss<0.1db,return loss< 5 dB
Interchangeability dB Additional loss<0.1db,return loss< 5 dB
Connection times times >1000
Operating Temperature ℃ -20℃- +70℃
Storage Temperature ℃ -20℃- +70℃

Application:

  • FTTH, LAN, Test equipment, Military industry.
  • Outside plant.
  • Premise networks.
  • Aerial distribution.
  • Measuring equipments.
  • Fiber optic communication system.
  • Optical active component and equipment.

LC UPC 12 Core Bundled Optic Fiber Patch Cord
