LC 12 Core 50/12 Multimode 1M 1.5M OM3 Fiber Optic Pigtail
LC 12 Core 50/12 Multimode 1M 1.5M OM3 Fiber Optic Pigtail
LC 12 Core 50/12 Multimode 1M 1.5M OM3 Fiber Optic Pigtail
LC 12 Core 50/12 Multimode 1M 1.5M OM3 Fiber Optic Pigtail
Specifications
Brand Name :
KNOFC or OEM
Model Number :
Pigtail LC/UPC OM3 12C
Certification :
CE/ISO9001
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
20000/week
Packaging Details :
Plastic bag
Fiber type :
Single mode 9/125
Connector type :
LC/UPC 12C
Length :
1M or Customized
Cable color :
White or Yellow
Cable diameter :
0.9mm
Insertion loss :
≤0.3dB
Operating Temperature :
-20°C to+50°C
Description

OM3 Fiber Optic Pigtail LC 12 Core 50/12 Multimode 1M 1.5M

Description:

The optical Fiber Connectors (Commonly we call Patch Cords) is a length of optical cable with connectors fixed on one ends to realize the optical path active connection. Pigtail is a length fiber cable with only one connector fixed on one end. According to the transmission medium, it divides Single Mode and Multi Mode; according to the connector structure type, it divides FC, SC, ST, MU, D4, E2000,LC etc.; according to the polished ceramic end-face, it divides PC, UPC and APC.

Features:

  • Good durability.
  • Good exchangeability.
  • High temperature stability.
  • Low insertion loss and back reflection loss.
  • Superior Quality Standard PC/UPC/APC Polishin.

Application:

  • FTTH, LAN, Test equipment, Military industry.
  • Outside plant.
  • Premise networks.
  • Aerial distribution.
  • Measuring equipments.
  • Fiber optic communication system.
  • Optical active component and equipment.

Specification:

Parameter Unit Mode Type PC UPC APC
Insertion Loss dB SM ≤0.3 ≤0.3 ≤0.3
Insertion Loss dB MM ≤0.3 ≤0.3 -----
Return Loss dB SM ≥50 ≥50 ≥60
Return Loss dB MM ≥35 ≥35 -----
Fiber cable Material PVC, LSZH
Fiber cable Diameter 0.9mm, 2.0mm, 3.0mm
Connector type SC, LC. ST. FC
Repeatability dB Additional loss<0.1db,return loss< 5 dB
Interchangeability dB Additional loss<0.1db,return loss< 5 dB
Connection times times >1000
Operating Temperature ℃ -20℃- +70℃
Storage Temperature ℃ -20℃- +70℃

LC 12 Core 50/12 Multimode 1M 1.5M OM3 Fiber Optic Pigtail

LC 12 Core 50/12 Multimode 1M 1.5M OM3 Fiber Optic Pigtail

LC 12 Core 50/12 Multimode 1M 1.5M OM3 Fiber Optic Pigtail
