GJBFJV Indoor Distribution 6 Core Multimode Fiber Optic Cable
GJBFJV Indoor Distribution 6 Core Multimode Fiber Optic Cable
GJBFJV Indoor Distribution 6 Core Multimode Fiber Optic Cable
GJBFJV Indoor Distribution 6 Core Multimode Fiber Optic Cable
Specifications
Brand Name :
KNOFC
Model Number :
GJBFJV 2 Core
Certification :
ISO9001/CE
Place of Origin :
China
MOQ :
1km
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
400000M/Week
Delivery Time :
8-10 working days
Packaging Details :
Wooden drum
Fiber type :
SM / MM
Fiber brand :
YOFC / Fiberhome / Corning
Fiber count :
2-24 Core
Protect layer :
Water Blocking Tape
Jacket material :
PVC / LSZH
Life expectancy :
more than 30 years
Operating Temperature :
-40°C to+70°C
Description

GJBFJV Indoor Distribution Fiber Optic Cable 6 Core Multimode

Description:

Distribution Tight Buffer Optical Cable use 2~48core Ø0.9mm or Ø0.6mm flame-retardant tight buffer fiber as optical communication medium. The tight buffer fiber wrapped with a layer of aramid yarn as strength member , then completed with a layer of PVC or LSZH material as out jacket.

Features:

1. Large fiber count small out diameter.
2. Non-metal central strength member.

Application:

1. Components for various indoor cables.
2. Suitable for patch cords and pigtails.
3. Suitable for communication equipment served.

Technical Parameters:

Cable type Diameter (mm) Weight (kg/km) Tensile strength
Long/short term (N)		 Crush Resistance Long/Short Term(N/100mm) Bending radius
Dynamic/static (mm)		 Storage temperature ( ℃ )
GJBFJV 2-8 5.0~6.0 25~35 100/300 300/1000 20D/10D -40~+70
GJBFJV12-24 6.0~7.0 35~50

Main mechanical & environmental performance test:

Item Test Method Acceptance Condition
Tensile Strength
IEC 794-1-2-E1		 - Load: Short term tension
- Length of cable: about 50m		 - Fiber strain £ 0.15%
- Loss change £ 0.1 dB @1550 nm
- No fiber break and no sheath damage
Crush Test
IEC 60794-1-2-E3		 - Load: Short term crush
- Load time: 1min		 - Loss change £ 0.05dB@1550nm
- No fiber break and no sheath damage.
Impact Test
IEC 60794-1-2-E4		 - Points of impact: 3
- Times of per point: 1
- Impact energy: 5J		 - Loss change £ 0.1dB@1550nm
- No fiber break and no sheath damage
Temperature Cycling Test
YD/T901-2001-4.4.4.1		 - Temperature step:
+20℃→-40℃→+70℃ →+20℃
- Time per each step: 12 hrs
- Number of cycle: 2		 - Loss change £ 0.05 dB/km@1550 nm
- No fiber break and no sheath damage.

GJBFJV Indoor Distribution 6 Core Multimode Fiber Optic Cable
