144 Cores Optical Cable Junction Box Dome Type 6 Port Fiber Splice Closure PC Plastic
144 Cores Optical Cable Junction Box Dome Type 6 Port Fiber Splice Closure PC Plastic
144 Cores Optical Cable Junction Box Dome Type 6 Port Fiber Splice Closure PC Plastic
144 Cores Optical Cable Junction Box Dome Type 6 Port Fiber Splice Closure PC Plastic
144 Cores Optical Cable Junction Box Dome Type 6 Port Fiber Splice Closure PC Plastic
144 Cores Optical Cable Junction Box Dome Type 6 Port Fiber Splice Closure PC Plastic
144 Cores Optical Cable Junction Box Dome Type 6 Port Fiber Splice Closure PC Plastic
144 Cores Optical Cable Junction Box Dome Type 6 Port Fiber Splice Closure PC Plastic
Specifications
Brand Name :
Twilight Optic
Model Number :
TW-GJSD033
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Piece/Pieces per Week
Delivery Time :
10-15 work days
Packaging Details :
Standard export carton packing.
Type :
GJS-D033
Size (mm) :
475*210
Accessible cables :
2in, 4 out
Cable diameter (mm) :
10~25
Maximum core for splice try :
24 (single core)
Maximum quantity of splice tray :
6
Capacity(core) :
144 (single core)
Sealing type: :
Thread mechanical sealing
Description

144 Cores optical cable junction box Dome Type 6 port fiber splice closure PC Plastic

Product Description

DOME type fiber optic splice closure is also called asvertical closure , it is suitable for FTTH accessing . Theinput and output are on the same side . An oval hole andfour round holes facilitates the operation . It is suitable foraerial , underground , conduct installation

Feature

Full mechanical sealing structure

High quality industrial plastic body material .

One oval hole and four round holes for cable entrancee

Suitable for cable diameter 10mm-25mm

Aerial , pole-mounting , direct buried and handheld application .

Protection level reaches IP68

360 degrees access , fiber bending > 40mm

.Maximum capacity : 144F single or 864F ribbon

Number of trays : 6 pcs x 24F .

TypeGJS-D033
Size(mm)470*210
Accessible cable2in 4out
Cable Diameter(mm)10-25
Max Core for splice try24core
Max of splice tray6
Capacity(Core)144Core


144 Cores Optical Cable Junction Box Dome Type 6 Port Fiber Splice Closure PC Plastic144 Cores Optical Cable Junction Box Dome Type 6 Port Fiber Splice Closure PC Plastic144 Cores Optical Cable Junction Box Dome Type 6 Port Fiber Splice Closure PC Plastic144 Cores Optical Cable Junction Box Dome Type 6 Port Fiber Splice Closure PC Plastic
