SMC Optic Distribution Box ODC Floor Outdoor Fiber Optic Distribution Cabinet
SMC Optic Distribution Box ODC Floor Outdoor Fiber Optic Distribution Cabinet
SMC Optic Distribution Box ODC Floor Outdoor Fiber Optic Distribution Cabinet
SMC Optic Distribution Box ODC Floor Outdoor Fiber Optic Distribution Cabinet
SMC Optic Distribution Box ODC Floor Outdoor Fiber Optic Distribution Cabinet
SMC Optic Distribution Box ODC Floor Outdoor Fiber Optic Distribution Cabinet
SMC Optic Distribution Box ODC Floor Outdoor Fiber Optic Distribution Cabinet
SMC Optic Distribution Box ODC Floor Outdoor Fiber Optic Distribution Cabinet
Specifications
Brand Name :
Twilight Optic or OEM
Model Number :
TW-CBSMC-144B
Place of Origin :
China
MOQ :
1
Price :
Can be disscussed
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
1000/Months
Delivery Time :
5-8 working days
Packaging Details :
Carton+Pallet
Material :
SMC
Color :
Grey White
Size :
1030*550*310MM
Splice tray :
12F or 24 F
Splice tray capacity :
12pcs or 6pcs
Package :
Carton box + Pallet
Warranty :
Many Years
Application :
Fiber Optic Cable Distribution
Description

Outdoor Waterproof Optical Distribution Fiber Optic Cabinet ODC 144 Core Floor Type

1. Specification

Parameters Specification
Model TW-CBSMC-144B
Max. No. of Cores 144F SC, Or 288F LC
Splitter Type cassette type
Max. No. of Splitters 14
Splice Tray Type 12 cores/tray or 24 cores
Max. No. of Splice Tray 24
Cabinet Material SMC
Adapter Panel FC square, SC, DLC (SC type)
Insulation Resistance (MΩ) 1000 @500V (DC)
Withstanding Voltage (V/min) 3000 (DC), no breakdown, no flashover
Installation Type Ground
Protection Rating IP65
Operating Temperature (°C) -40~ +60
Dimensions (mm) 1035(H) x 555(W) × 310(D)
Weight (kg) 45

Features:

  • 1. Cabinets with SMC material: heat insulation, waterproof and good corrosion resistance
  • 2. High performance rubber seals: effective rain and dust proof for outdoor environment
  • 3. Modules individually removable: easy to construct and maintain
  • 4. Reliable cable fixing and grounding protection devices
  • 5. Safe and reliable fiber optic storage and protection

Applications:

  • 1. FTTH access networks
  • 2. Telecommunication networks
  • 3. CATV networks
  • 4. Local Area Networks

More photos for reference:

SMC Optic Distribution Box ODC Floor Outdoor Fiber Optic Distribution Cabinet

SMC Optic Distribution Box ODC Floor Outdoor Fiber Optic Distribution Cabinet

SMC Optic Distribution Box ODC Floor Outdoor Fiber Optic Distribution Cabinet

SMC Optic Distribution Box ODC Floor Outdoor Fiber Optic Distribution Cabinet
