Specifications
Brand Name :
Twilight Optic
Model Number :
TW-GJS(04)-5E
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Piece/Pieces per Week
Delivery Time :
10-15 work days
Packaging Details :
Standard export carton packing.
Product name :
96Core 2in 2out inline splice closure
Material :
ABS
Color :
black
Demention :
355*180*65mm
Diameter of cable :
10-22mm
Protection :
IP65
Cable entry ports :
4 pieces
Capacity of FOSC :
96core
Description

24 48 72 96 Core Outdoor Fiber Splice Enclosure 2in 2out Optical Fiber Closure For Overhead Pipeline Underground

Product Description

This product is suitable for cables applied in the straight line or branch line(one into two, one into three) connection of optical cables (≤φ22mm, single fiber or ribbon fibers), which can be laid overhead,in the pipeline, underground or in the well. It is also applied to the connection of all-plastic phone cables.

Features

1. All property indexes are in accordance with National YD/T814-2001 Standard.
2. The case body is made from imported high-intensity engineering plastics(ABS) and formed the shape with mould under high pressure. It is in the square shape, with the advantages of less
weight, high mechanical intensity, corrosive-resistance, anti-thunderstruck and long service life.
3. The case body and cable entrance are sealed with adhesive rubber strip with reliable sealing capability. It can be re-opened and easy to maintain.
4. supplied with ports corresponding plug, so the users can choose them according to the actual use of optical cables.
5. Independent insulation grounding device, make the cable grounding flexible, convenient and safe.
6. Outer metal component and fixing unit are made from stainless steel, so it can be repeatedly used in different environment.

Advantage

Waterproof /Anti oxidation
Flame retardant/Earthquake resistant
Low insertion loss and back reflection loss
Good exchangeability
Good Durability
High temperature stability.
Precise connector

Specification

Model TW-GJS(04)-5E
Type Inline type
Number of Inlet/Outlet ports 4 ports,2in 2out
Cable Diameter 10-22mm
Maximum Capacity 96 fibers
Capacity per Splice Tray 24Cores
Quantity of Splice Tray 4pcs
Body Material ABS
Assembling method Aerial, direct buried, pipelined, wall mounting, manhole
Dimension 355(L)×180(W)×65(H)mm
Net Weight 2.5~2.7KG
Temperature -40℃~65℃
