288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box
288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box
288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box
288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box
288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box
288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box
288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box
288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box
288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box
288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box
Specifications
Brand Name :
Twilight Optic
Model Number :
GJS-H005
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Piece/Pieces per Week
Delivery Time :
10-15 work days
Packaging Details :
Standard export carton packing.
Product name :
6port inline splice closure
Material :
strengthen PC
Color :
black
SZIE :
450*220*160MM
Diameter of cable :
7mm to 23mm
Protection level :
IP-68
Cable entry ports :
6 Ports 23mm 3 in 3 out
Max Capacity :
24-288core
Description

288 Core Fiber Optic Splice Closure Waterproof Ip68 Horizontal Type Fiber Cable Joint Box

Product Description

GJS-H005 fiber optic splice closure is able to hold up to 96 splicing points, the fully rugged design enable it to work in the harshest environment,the mechanical locking system maintains the protection level at IP68 grade,it is suitable for direct buried, pipeline, wall mounted, manhole and handhole installation.6 cable entrance(7-16mm)supports 3 cables entry from left and 3 cables entry from right side.

Features

1. Water-proof design with IP-68 Protection level.
2. Half design with easy access and tight water proof.
3. Impact test:IK10,Pull Force:100N,Full rugged design
4. All stainless metal plate and anti-rusting bolts, nuts
5. Maximum splice capacity: 288 fibers(12 trays x 24F).
6. Suitable for the fusion splice or mechanical splice.
7. Mechanical sealing with rubber protection tube.

Application

1. Direct buried installation
2. Pole mounted installation
3. Wall mounted installation
4. Man hole and hand hole installation
5. FTTH access layer

Product name 3 in 3 out inline splice closure
Material strengthen PC
Color black
Demention 450*220*160MM
Cable entry ports 6 pieces
Protection level IP-68
Number of packing 10 pcs/ctn
Weight 3.8kg/pcs
Diameter of cable 7mm-23mm
Capacity of FOSC Bunchy 24-288 cores

288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box

288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box

288 Core Fiber Optic Splice Closure IP68 Horizontal Type Fiber Cable Joint Box
