Low Speed High Torque Disc Valve Hydraulic Motor Eaton Char-Lynn 104 , 105 , 106
Low Speed High Torque Disc Valve Hydraulic Motor Eaton Char-Lynn 104 , 105 , 106
Low Speed High Torque Disc Valve Hydraulic Motor Eaton Char-Lynn 104 , 105 , 106
Low Speed High Torque Disc Valve Hydraulic Motor Eaton Char-Lynn 104 , 105 , 106
Low Speed High Torque Disc Valve Hydraulic Motor Eaton Char-Lynn 104 , 105 , 106
Low Speed High Torque Disc Valve Hydraulic Motor Eaton Char-Lynn 104 , 105 , 106
Specifications
Brand Name :
Hanjiu
Model Number :
Orbit Motor BMS
Certification :
CE
Place of Origin :
China
MOQ :
50 units
Price :
Negotiable
Payment Terms :
T/T, Western Union,Paypal .
Supply Ability :
100,000 units / Year
Delivery Time :
10-15 working days
Packaging Details :
Carton packing , with a tray or wooden box if needed .
Product name :
Hydraulic Gear Motors
Features :
Small Size, Compact Structure, High Torque, Clockwise & Counterclockwise, Long Life
Displacement :
50cc,80cc,100cc,125cc,160cc......500cc
Applications :
Agricultural machine, Transportation, Construction equipment, Metallurgical, Marine, etc.
Replacement :
, Eaton , M+S
Flange :
2 bolt flange , 4 bolt flange
Description

Low Speed High Torque Disc Valve Hydraulic Motor Eaton Char-Lynn 104 , 105 , 106

We specialize in the production of hydraulic products, which can replace imported brands, quality and cheap

FEATURES

  1. HANJIU BMP/BM1= OMP = EATON H = M+S MP
  2. HANJIU BMR/BM2= OMR = EATON S = M+S MR
  3. HANJIU BMH/BM4= OMH = M+S MH
  4. HANJIU BMS/BM5= OMS = EATON 2000 = M+S MS
  5. HANJIU BMT/BM6= OMT = EATON 6000 = M+S MT

Hanjiu BMS series hydraulic motor replaces Eaton Char-Lynn 104,105,106

Shijiazhuang Hanjiu Technology Co., Ltd mainly products catalogue:
1. Hanjiu Hydraulic Orbital motors: BMP, BMR, BMS, BMH, BMT, BMV can replace , EATON CHAR-LYNN, M+S, etc.

2. Hanjiu Orbital Steering Units: 101S= OSPC, 101= OSPB; 102S= M+S HKUS, 060= Eaton 45 series

3. Hanjiu Gear pumps: CBT, CBG-F3, GPC4, G5, Quality same as Parker Gear Pumps, also can replace Caproni, Rexroth etc. We also accept OEM.

4. Hanjiu Hydraulic Monoblock Valve: P40, P80, etc.

► Specification

Same than OMS, M+S MS, Eaton 2000 Series

Type BMS
80		 BMS
100		 BMS
125		 BMS
160		 BMS
200		 BMS
250		 BMS
315		 BMS
375
Geometric displacement
(cm3 /rev.)		 80.6 100.8 125 157.2 200 252 314.5 370
Max. speed (rpm) cont. 800 748 600 470 375 300 240 200
int. 988 900 720 560 450 360 280 240
Max. torque (N·m) cont. 190 240 310 316 400 450 560 536
int. 240 300 370 430 466 540 658 645
peak 260 320 400 472 650 690 740 751
Max. output (kW) cont. 15.9 18.8 19.5 15.6 15.7 14.1 14.1 11.8
int. 20.1 23.5 23.2 21.2 18.3 17 18.9 17
Max. pressure drop (MPa) cont. 17.5 17.5 17.5 15 14 12.5 12 10
int. 21 21 21 21 16 16 14 12
peak 22.5 22.5 22.5 22.5 22.5 20 18.5 14
Max. flow (L/min) cont. 65 75 75 75 75 75 75 75
int. 80 90 90 90 90 90 90 90
Max. inlet pressure (MPa) cont. 25 25 25 25 25 25 25 25
int. 30 30 30 30 30 30 30 30
Weight (kg) 9.8 10 10.3 10.7 11.1 11.6 12.3 12.6

Low Speed High Torque Disc Valve Hydraulic Motor Eaton Char-Lynn 104 , 105 , 106

Low Speed High Torque Disc Valve Hydraulic Motor Eaton Char-Lynn 104 , 105 , 106

► Application

BMS hydraulic motoris one type of high torque Iow speed hydraulic motors, with high efficiency and long life. BMS motor has a wide Speed rangee, high starting torque and rotating stable at high speed Compact and light, it can be connected to working machine directly, adapted to all kinds of Iow speed heavy load facilities.
BMShydraulic motors are widely applied in agriculture machinery, fishing machinery, plastic industry, mining, and construction machinery.

Low Speed High Torque Disc Valve Hydraulic Motor Eaton Char-Lynn 104 , 105 , 106

Shijiazhuang HanJiu technology co., LTD., is specialized in the production of BM series cycloid hydraulic motor, the BZZ redirector enterprise, my factory has dozens of high-quality, professional engineering and technical personnel, and more than in 2010, has introduced the most advanced production equipment, is in northern China's largest factories, production of more than 300000 units a year.

Low Speed High Torque Disc Valve Hydraulic Motor Eaton Char-Lynn 104 , 105 , 106

My factory specializes in designing and producing the motors and steering gear of any type, from large to small, from low to high, and so on. And can replace , Eaton, M+S series models. Products are widely used in engineering machinery, mining machinery, metallurgical machinery, petroleum machinery, agricultural machinery, injection molding machinery, fishery machinery, military engineering and other fields.

Low Speed High Torque Disc Valve Hydraulic Motor Eaton Char-Lynn 104 , 105 , 106

My factory take the good faith first, quality first for the purpose, from the employee on-boarding, raw materials into the factory, from parts processing, assembly proposal until products, has a relatively perfect system of product quality. And through CE certification.

Please do not hesitate to contact us for further information, inquiries or orders.

Thank you for choosing 'Hanjiu' Hydraulics.
