2 Flange Low Speed High Torque Hydraulic Motor 25mm Shaft Size For Construction Equipment
2 Flange Low Speed High Torque Hydraulic Motor 25mm Shaft Size For Construction Equipment
2 Flange Low Speed High Torque Hydraulic Motor 25mm Shaft Size For Construction Equipment
2 Flange Low Speed High Torque Hydraulic Motor 25mm Shaft Size For Construction Equipment
2 Flange Low Speed High Torque Hydraulic Motor 25mm Shaft Size For Construction Equipment
2 Flange Low Speed High Torque Hydraulic Motor 25mm Shaft Size For Construction Equipment
Specifications
Brand Name :
HANJIU
Model Number :
BMR160,BMR200,BMR315,BMR400
Certification :
CE
Place of Origin :
China
MOQ :
50 Pieces
Price :
Negotiable
Payment Terms :
L/C, T/T, D/A, D/P, Western Union
Supply Ability :
80000 Pieces One Year
Packaging Details :
Carton Box
Product Name :
Hydraulic Motor BMR
Displacement :
160CC - 400CC
Flnge :
2 flange
Power :
Hydraulic Oil
Features :
Match OMR Motor
Shaft size :
25mm
Description

151-1234 , 151-1235 , 151-1237 , 151-1243 OMR / BMR Orbital Motors

BMR / OMR 151-1234 , 151-1235 , 151-1237 , 151-1243 Motor Details:

• Shaft : 25mm

• Oil Port : G1/2"

• Drain port : G1/4"

• Flange : 2 flange

• Key : 8x7x32mm

Application

1. Construction equipment

2. Agricultural equipment

3. Forestry equipment

4. Road Sweepers

Specification

Type BMR
BMRS
36		 BMR
BMRS
50		 BMR
BMRS
80		 BMR
BMRS
100		 BMR
BMRS
125		 BMR
BMRS
160		 BMR
BMRS
200		 BMR
BMRS
250		 BMR
BMRS
315		 BMR
BMRS
375
Geometric displacement (cm3 /rev.) 36 51.7 81.5 102 127.2 157.2 194.5 253.3 317.5 381.4
Max. speed (rpm) cont. 1085 960 750 600 475 378 310 240 190 155
int. 1220 1150 940 750 600 475 385 300 240 190
Max. torque (N·m) cont. 72 100 195 240 300 360 360 390 390 365
int. 83 126 220 280 340 430 440 490 535 495
peak 105 165 270 320 370 460 560 640 650 680
Max. output (kW) cont. 8.5 9.5 12.5 13 12.5 12.5 10 7 6 5
int. 9.8 11.2 15 15 14.5 14 13 9.5 9 8
Max. pressure drop (MPa) cont. 14 14 17.5 17.5 17.5 16.5 13 11 9 7
int. 16.5 17.5 20 20 20 20 17.5 15 13 10
peak 22.5 22.5 22.5 22.5 22.5 22.5 22.5 20 17.5 15
Max. flow (L/min) cont. 40 50 60 60 60 60 60 60 60 60
int. 45 60 75 75 75 75 75 75 75 75
Weight (kg) 6.5 6.7 6.9 7 7.3 7.6 8 8.5 9 9.5

2 Flange Low Speed High Torque Hydraulic Motor 25mm Shaft Size For Construction Equipment

2 Flange Low Speed High Torque Hydraulic Motor 25mm Shaft Size For Construction Equipment

2 Flange Low Speed High Torque Hydraulic Motor 25mm Shaft Size For Construction Equipment

Shijiazhuang Hanjiu Technology Co.,Ltd

Sale Director // E-mail: sales05@sjzhjsm.com // Skype: Simon-Hanjiu Hydraulics // WhatsApp: +86 15530109495 // Website:www.hjhydraulic.com
