Specifications
Brand Name :
HANJIU
Model Number :
BMR / OMR / MR
Certification :
CE
Place of Origin :
China
MOQ :
50 pieces
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
90000 pieces per year
Delivery Time :
3-5 work days
Packaging Details :
Carton box
Product Name :
Orbit Hydraulic Motor BMR
Features :
Same ,M+S Motors
Displacement :
50cc - 500cc
Application :
geological drilling equipment , agricultural and forest machinery
Description

Orbit Hydraulic Motor BMR Series For Forestry Hydraulic Machinery Equipment

► Characteristic Features

1. The output shaft, with the deep groove ball bearing, can bear certain axial force and radial force.


2. With the axial oil distribution structur, it is of smaller size and less weight.


3. With two inner check valves, no drain connection.


4. With cycoid group with the roller, it has a small friction nd high mechanical efficiency.

► Specification

Technical data for BMR with 25 and 1 in and 1 in splined and 28.56 tapered shaft:
Type BMR
BMRS
36		 BMR
BMRS
50		 BMR
BMRS
80		 BMR
BMRS
100		 BMR
BMRS
125		 BMR
BMRS
160		 BMR
BMRS
200		 BMR
BMRS
250		 BMR
BMRS
315		 BMR
BMRS
375
Geometric displacement (cm3 /rev.) 36 51.7 81.5 102 127.2 157.2 194.5 253.3 317.5 381.4
Max. speed (rpm) cont. 1085 960 750 600 475 378 310 240 190 155
int. 1220 1150 940 750 600 475 385 300 240 190
Max. torque (N·m) cont. 72 100 195 240 300 360 360 390 390 365
int. 83 126 220 280 340 430 440 490 535 495
peak 105 165 270 320 370 460 560 640 650 680
Max. output (kW) cont. 8.5 9.5 12.5 13 12.5 12.5 10 7 6 5
int. 9.8 11.2 15 15 14.5 14 13 9.5 9 8
Max. pressure drop (MPa) cont. 14 14 17.5 17.5 17.5 16.5 13 11 9 7
int. 16.5 17.5 20 20 20 20 17.5 15 13 10
peak 22.5 22.5 22.5 22.5 22.5 22.5 22.5 20 17.5 15
Max. flow (L/min) cont. 40 50 60 60 60 60 60 60 60 60
int. 45 60 75 75 75 75 75 75 75 75
Weight (kg) 6.5 6.7 6.9 7 7.3 7.6 8 8.5 9 9.5

Professional BMR Hydraulic Motor Compact Volume For Geological Drilling Equipment

► Application

BMR Hydraulic motors are dedicated to

1. Agriculture

2. Forestry

3. Mining machines

Professional BMR Hydraulic Motor Compact Volume For Geological Drilling Equipment
