Specifications
Brand Name :
HANJIU
Model Number :
BZZ
Certification :
CE
Place of Origin :
CHINA
MOQ :
50 Sets
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1000000 Sets Per Year
Delivery Time :
10-15 work days
Packaging Details :
Carton Packing and finally with a Tray, or Wooden Box
Product Name :
General Steering Components Steering units
Feature :
Check valve, External valve block option
Technology :
Open center non-reaction, Open center reaction, Close center non-reaction, Load sensing
Oil Port :
G1/2"
Displacement :
50cc-1000cc
Application :
Agricultural machine, Transportation, Construction equipment, Metallurgical, Marine, etc.
Description

Hydraulic Orbitrols, Steering Units BZZ For Class / Tractors, Loaders

Introduction:

Hydraulic steering control units (BZZ),hydraulic motor

BZZ1, BZZ2, BZZ3 Hydraulic steering control units(SCU), new design, better performance. Widely applied to low speed and heavy load vehicles E.g. construction machinary, forklift, tractor, harvester and helm control etc.

Advantages:

The advantages of the hydraulic steering control units:

1. Low cost, reliable.
2. No load reaction on the steering wheel comfortable.
3. Manual operation available when the pump doesnt work.
4. Low control torque, continuous operation.
5. According to the system, different function and pressure level valves available.

Specification:

Type Displacement
(mL/r)		 Flow
(L/min)		 Max.input
pressure (MPa)		 Max. cont. back
pressure (MPa)		 Length (mm)
BZZ (1.2.3)–E50 * 50 4 16 2.5 140
BZZ(1.2.3) –E63 * 60 5 141
BZZ(1.2.3) –E80 * 80 6 142.5
BZZ(1.2.3) –E100 * 10 7.5 145
BZZ(1.2.3) –E125 * 125 9.5 148
BZZ (1.2.3)–E160 * 160 12 153
BZZ(1.2.3) –E200 * 200 15 158
BZZ (1.3)–E250 * 250 19 164
BZZ (1.3)–E280 * 280 21 169
BZZ (1.3)–E315 * 315 24 174
BZZ(1.3) –E400 * 400 30 184
BZZ (1.3)–E500 * 500 38 197
BZZ(1.3) –E630 * 630 48 216
BZZ (1.3)–E800 * 800 60 236
BZZ (1.3)–E1000 * 10000 75 262

Continuous Operation Hydraulic Steering Motor Steering Units BZZ For Forklift / Tractor
Applications:

Its role is to increase the power steering wheel steering transmission to the transmission mechanism and change the direction of transmission.

Widely used in agricultural machinery, shipbuilding machinery, garden machinery, road maintenance machinery, forestry machinery, construction machinery and mining machinery and other low-speed heavy vehicles.

With it, the driver can achieve greater steering force control with a smaller steering force, and the performance is safe and reliable, the operation is light and flexible.
