High Performance Hydraulic Gear Motor BMM Cast Iron Material For Brush Cutters
High Performance Hydraulic Gear Motor BMM Cast Iron Material For Brush Cutters
High Performance Hydraulic Gear Motor BMM Cast Iron Material For Brush Cutters
High Performance Hydraulic Gear Motor BMM Cast Iron Material For Brush Cutters
High Performance Hydraulic Gear Motor BMM Cast Iron Material For Brush Cutters
High Performance Hydraulic Gear Motor BMM Cast Iron Material For Brush Cutters
High Performance Hydraulic Gear Motor BMM Cast Iron Material For Brush Cutters
High Performance Hydraulic Gear Motor BMM Cast Iron Material For Brush Cutters
Specifications
Brand Name :
HANJIU
Model Number :
BMMM
Certification :
CE
Place of Origin :
China
MOQ :
50 sets
Price :
Negotiable
Supply Ability :
60,000 sets a year
Delivery Time :
10-15 working days
Packaging Details :
carton packaging, and finally with a tray or wooden box
Product Name :
Hydraulic Motors
Material :
CAST IRON
Color :
no paint/blue/black
Internal structure :
gerolor gear set
Description

Hydraulic Gear Motor BMM Incorporates The Latest Advances For Smooth Performance, Efficiency And Durability

1) Intermittent operation: the permissible values may occur for max. 10% of every minute.

2) Peak load: the permissible values may occur for max. 1% of every minute.

3) Operation by lower speeds may be slightly less smooth.

Specification :

HANJIU BMM
M+S MM
EATON J Series
OMM

Type BMM8 BMM12 BMM20 BMM32 BMM40 BMM50
displacement 8.2 12.9 19.9 31.6 39.8 50.3
Max speed(rpm) rated 1537 1256 814 513 452 358
Cont. 1950 1550 1000 630 500 400
int. 2450 1940 1250 800 630 500
Max Torque
(N*M)		 rated 8 13 19 31 37 33
Cont. 11 16 25 40 45 46
int. 15 23 35 57 70 88
peak 21 33 51 64 82 100
Max speed
(kw)		 rated 1.3 1.7 1.7 1.7 1.7 1.2
Cont. 1.8 2.4 2.4 2.4 2.2 1.8
int. 2.6 3.2 3.2 3.2 3.2 3.2
Max pressure
drop(MPa)		 rated 9 9 9 9 8.5 6
Cont. 10 10 10 10 9 7
int. 14 14 14 14 14 14
peak 20 20 20 16 16 16
Max flow(L/min) rated 14 18 18 18 20 20
Cont. 18 20 20 20 20 20
int. 20 25 25 25 25 25
Weight(kg) 1.9 2 2.1 2.2 2.3 2.4

  • Model - Disc valve, roll-gerotor;
  • Flange and wheel mount;
  • Short motor;
  • Tacho connection;
  • Speed sensor connection;
  • Side and rear ports;
  • Shafts - straight, splined and tapered;
  • Metric and BSPP ports;
  • Other special features.

Applications:

HANJIU Hydraulic Motors BMM Series used for the following field:

1. Brush cutters
2. Mower
3. Forestry equipment
4. Ship Cleaning Underwater

5. Plastic injection moulding
