Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft
Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft
Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft
Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft
Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft
Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft
Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft
Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft
Specifications
Brand Name :
HANJIU
Model Number :
BMK2-200-E6-G-SU
Certification :
CE
Place of Origin :
China
MOQ :
100 Pieces
Price :
90 USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, Payple
Supply Ability :
10000 pieces per year
Delivery Time :
35 - 45 work days
Packaging Details :
1 pc/ inner carton, 2 pcs/ outer carton, 31x31x17cm, transport with wooden pallet, 650 pcs/ 20GP, 1300 pcs/ 40GP
Type :
Orbital motor, Hydraulic motor
Brand :
HANJIU
Model No. :
BMK2-200-E6-G-SU
Displacement :
200ml/r
Flange :
4 bolts,oval flange
Shaft :
31.75mm key shaft
Port size :
7/8-14UNF O-RING
Drain line :
7/16-20UNF
Description

BMK2 Hydraulic Motor Char-Lynn eaton 2K motors,200cc 106.4mm oval flange,31.75mm key shaft

Quick review:

order code:BMK2-200-E6-G-SU
Output volume (cc/rev): 200cc
Shaft Ø (mm): 31.75mm,key shaft
max r.p.m.: 577
Torque max. (Nm): 665
Pressure difference (bar): 310
Volume flow max. (l/min): 115
Shaft seal version: Standard
Ports threads: 7/8-14UNF O-RING
Leakage oil connection: 7/16-20UNF

Main specifiction:

Main Specifications:
Type BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2
65 80 100 125 160 200 250 315 400 475
Geometric displacement
(cm3 /rev.)		 65 80 100.9 129.8 156.8 193.4 242.5 304.3 390.8 485
Max. speed (rpm) cont. 835 800 742 576 477 385 308 246 191 153
int. 990 980 924 720 713 577 462 365 287 230
Max. torque (N·m) cont. 185 235 295 385 455 540 660 765 775 845
int. 245 345 445 560 570 665 820 885 925 930
Max. pressure drop (MPa) cont. 20.5 21 21 21 20.5 20.5 20.5 21 15.5 12
int. 27.5 31 31 31 26 26 26 24 17 14
peak 31 31 31 31 31 31 31 31 20.5 17
Max. flow (L/min) cont. 55 65 75 75 75 75 75 75 75 75
int. 65 80 95 95 115 115 115 115 115 115
Weight (kg) 9.2 9.4 9.7 10 10.2 10.5 11 11.5 12 12.4
* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.

Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft

Measurement:

Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft

Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft

Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft

Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key ShaftBmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft

More Char-lynn version hydraulic motors available:

Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft

About Hanjiu:

From China, design, develop and manufacture hydraulic orbital motors. Shipped to all over the world, customers use Hanjiu hydraulic motors directly as compatible motors for Danfoss, M+S, Eaton, Parker, White, Dana Brevini. Obtain the maximum benefit with the minimum cost, and you have no risk in cooperating with Hanjiu. If you are hydraulic motor importer, wholesaler, OEM factory, contact us to discuss cooperation and get big customer discount.

Bmk2 Hydraulic Motor Char Lynn Eaton 2k Motors 200cc 106.4mm Oval Flange 31.75mm Key Shaft
