OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft
OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft
OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft
OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft
OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft
OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft
OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft
OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft
OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft
OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft
OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft
OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft
Specifications
Brand Name :
HANJIU
Model Number :
BMPHX-050-H2-K-S-TRB
Certification :
CE
Place of Origin :
China
MOQ :
100 Pieces
Price :
47
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
10000 pieces per year
Delivery Time :
35 work days
Packaging Details :
Box, Pallet
Item :
Hydraulic Motor
Direction :
Left and right
OEM # :
BMPHX-050-H2-K-S-TRB
Displacement :
50cc
Flange :
2-Bolt
Shaft Size :
1" shaft with woodruff key
Port :
7/8-14 O-ring
Speed :
1150 - 1450 rpm
Torque :
100 - 148 Nm
Max Flow :
60 - 75 Lpm
Description

OMP MP H BMPH series hydraulic motor 50ml/r 2 bolt flange 1'' shaft

Quick review:
Item , Hydraulic Motor
Direction , Left and right
OEM #, BMPHX-050-H2-K-S-TRB
Displacement , 50cc
Flange , 2-Bolt
Shaft Size , 1" shaft with woodruff key
Port , 7/8-14 O-ring
Speed , 1150 - 1450 rpm
Torque , 100 - 148 Nm
Max Flow , 60 - 75 Lpm

Main Specifications:
Technical data for BMP with 25 and 1 in and 1 in splined and 28.56 tapered shaft:
Type BMP
BMPH
BMPW
36		 BMP
BMPH
BMPW
50		 BMP
BMPH
BMPW
80		 BMP
BMPH
BMPW
100		 BMP
BMPH
BMPW
125		 BMP
BMPH
BMPW
160		 BMP
BMPH
BMPW
200		 BMP
BMPH
BMPW
250		 BMP
BMPH
BMPW
315		 BMP
BMPH
BMPW
400		 BMP
BMPH
BMPW
500
Geometric displacement (cm3 /rev.) 36 51.7 77.7 96.2 120.2 157.2 194.5 240.3 314.5 389.5 486.5
Max. speed (rpm) cont. 1500 1150 770 615 490 383 310 250 192 155 120
int. 1650 1450 960 770 615 475 385 310 240 190 150
Max. torque (N·m) cont. 55 100 146 182 236 302 360 380 375 360 385
int. 76 128 186 227 290 370 440 460 555 525 560
peak 96 148 218 264 360 434 540 550 650 680 680
Max. output (kW) cont. 8 10 10 11 10 10 10 8.5 7 6 5
int. 11.5 12 12 13 12 12 12 10.5 8.5 7 6
Max. pressure drop (MPa) cont. 12.5 14 14 14 14 14 14 11 9 7 6
int. 16.5 17.5 17.5 17.5 17.5 17.5 17.5 14 14 10.5 9
peak 22.5 22.5 22.5 22.5 22.5 22.5 22.5 18 16 14 12
Max. flow (L/min) cont. 55 60 60 60 60 60 60 60 60 60 60
int. 60 75 75 75 75 75 75 75 75 75 75
Weight (kg) 5.6 5.6 5.7 5.9 6 6.2 6.4 7 6.9 7.4 8

OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft

OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft

OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft

OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft

OMP MP H BMPH Series Hydraulic Motor 50ml/R 2 Bolt Flange 1'' Shaft

APPLICATIONS

Agricultural augers, harvesters, seeders, snow plows, railroad maintenance equipment, concrete and asphalt equipment and more.

FEATURES

Designed for medium duty applications, it's use industry-proven spool valve technology, combined with state-of-the-art gerotors. In addition, a wide variety of mounting flanges, shafts, ports and valving options provide design flexibility. Direction of shaft rotation and shaft speed can be controlled easily and smoothly throughout the speed range of the motor, and equipment can be driven direct, eliminating costly mechanical components.
