109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor
109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor
109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor
109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor
109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor
109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor
109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor
109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor
109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor
109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor
109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor
109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor
Specifications
Brand Name :
HANJIU
Model Number :
109S-1-40-09-A
Certification :
CE
Place of Origin :
CHINA
MOQ :
100 Sets
Price :
60 usd
Payment Terms :
T/T
Supply Ability :
1000000 Sets Per Year
Delivery Time :
25 - 35 work days
Packaging Details :
Carton, Pallet, Box
Product :
Steering Valve
Model :
109S-1-40-09-A
Power :
Hydraulic Driving
Founction :
ON
Relief valve :
Yes
Shock valve :
Yes
Relief valve ressure :
16 Mpa
Check valve :
Yes
Description

Welcome!
We're manufacture from China, provide Hydraulic Steering Unit to fit Tractors, trucks, loaders, forklifts, excavators, backholes, cranes, aerial platforms, farm machines, etc.
Partners include OEM, hydraulic importers, hydraulic distributors

Please see product introduction below:

109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve

Parameters:

Type 109*-1-***-**-*
Displacement(mL/r) 20 32 40 50 63 80
Rated flow(L/min) 3~20
Rated Pressure(MPa) 12.5
Relief Valve Pressure Settings(MPa) 06,07,08,09,10
Shock Valves Pressure Settings(MPa) 12,13,14,15,16
Steering Torque(N·m) ≤1.8
Max．Cont．Preesure in Line T-PT(MPa) 1
Dimension L(mm) 87 92 96 100 105 113

109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor

109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor

109S-1-40-09-A ON OSPM 40 ON Equivalent Steering Control Valve For Mini Forklift Mini Tractor

Features:

109 series hydraulic steering unit is an integrated orbital steering unit with 4/5 tooth structure.This kind of steering unit has a small and exquisite structure with integrated check valve, relief valve and shock valves and its mounting dimension conforms to international standard.

Application:

This kind of steering unit is widely used in mini vehicles, such as mini forklift, mini tractor (and other agricultural machinery), mini earthmoving machinery, mini municipal vehicle, etc. It can obtain more steering output torque through input of less power, with features of easy, flexible and reliable operation.

More Steering Unit recommendations:

Code Hanjiu Code Description Displacement Fuction
OSPC / HKUS 101S Aftermarket 50cc ON/OR/LS
OSPC / HKUS 101S Aftermarket 80cc ON/OR/LS
OSPC / HKUS 101S Aftermarket 100cc ON/OR/LS
OSPC / HKUS 101S Aftermarket 125cc ON/OR/LS
OSPC / HKUS 101S Aftermarket 160cc ON/OR/LS
OSPC / HKUS 101S Aftermarket 200cc ON/OR/LS
OSPC / HKUS 101S Aftermarket 250cc ON/OR/LS
OSPC / HKUS 101S Aftermarket 315cc ON/OR/LS
OSPC / HKUS 101S Aftermarket 400cc ON/OR/LS
OSPC / HKUS 101S Aftermarket 500cc ON/OR/LS
OSPC / HKUS 101S OEM level 50cc ON/OR/LS/CN
OSPC / HKUS 101S OEM level 80cc ON/OR/LS/CN
OSPC / HKUS 101S OEM level 100cc ON/OR/LS/CN
OSPC / HKUS 101S OEM level 125cc ON/OR/LS/CN
OSPC / HKUS 101S OEM level 160cc ON/OR/LS/CN
OSPC / HKUS 101S OEM level 200cc ON/OR/LS/CN
OSPC / HKUS 101S OEM level 250cc ON/OR/LS/CN
OSPC / HKUS 101S OEM level 315cc ON/OR/LS/CN
OSPC / HKUS 101S OEM level 400cc ON/OR/LS/CN
OSPC / HKUS 101S OEM level 500cc ON/OR/LS/CN
OSPB / HKU 101 Aftermarket 50cc ON/OR/LS
OSPB / HKU 101 Aftermarket 80cc ON/OR/LS
OSPB / HKU 101 Aftermarket 100cc ON/OR/LS
OSPB / HKU 101 Aftermarket 125cc ON/OR/LS
OSPB / HKU 101 Aftermarket 160cc ON/OR/LS
OSPB / HKU 101 Aftermarket 200cc ON/OR/LS
OSPB / HKU 101 Aftermarket 250cc ON/OR/LS
OSPB / HKU 101 Aftermarket 315cc ON/OR/LS
OSPB / HKU 101 Aftermarket 400cc ON/OR/LS
OSPB / HKU 101 Aftermarket 500cc ON/OR/LS
OSPB / HKU 101 OEM level 50cc ON/OR/LS/CN
OSPB / HKU 101 OEM level 80cc ON/OR/LS/CN
OSPB / HKU 101 OEM level 100cc ON/OR/LS/CN
OSPB / HKU 101 OEM level 125cc ON/OR/LS/CN
OSPB / HKU 101 OEM level 160cc ON/OR/LS/CN
OSPB / HKU 101 OEM level 200cc ON/OR/LS/CN
OSPB / HKU 101 OEM level 250cc ON/OR/LS/CN
OSPB / HKU 101 OEM level 315cc ON/OR/LS/CN
OSPB / HKU 101 OEM level 400cc ON/OR/LS/CN
OSPB / HKU 101 OEM level 500cc ON/OR/LS/CN
