Specifications
Brand Name :
HANJIU
Model Number :
2p40
Certification :
CE
Place of Origin :
CHINA
MOQ :
30 Sets
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
300000 sets per year
Delivery Time :
10-15 work days
Packaging Details :
Carton Packing and finally with a Tray, or Wooden Box
Material :
cast iron
Warranty :
12 months
Spool :
2 levers
Flow :
40liters
Spool function :
spring control
oil ports :
G3/8
Description

40 liter monoblock control valve, 2P40 , two spools , G 3/8" , open center spool , 2P40 A1C1 GKZ1

Directional control valves are one of the core elements in a hydraulic system. They help directing the fluid to different components. P40 series are monoblock directional control valves and manufactured with up to seven levers. Hanjiu offer 2P40 A1C1 GKZ1 directional control valve.

Product details:

P40 - series
A - spool diagram
1 - spool centering with springs
G - type of connecting thread: P, A, B - G3/8; T, N - G1/2
KZ1 - type of manual control

Ambient temperature -40C...+60C
Viscosity 12 ...800 mm2/s
Fluid temperature -15C...+80C
Filtration 10 to NAS 1638
Max operating pressure 250bar
Back pressure 50 bar
Nominal flow 40 l/min
Leakage(A,B-T) 15cm3/min at 120bar
Spool stroke 6 mm
Actuating force < 200 N
Modification/ Spools with 1 to 7
40 Liter Monoblock Control Valve 2P40 Two Spools G 3/840 Liter Monoblock Control Valve 2P40 Two Spools G 3/8

2P40 A1A1 SKZ1
2P40 A1C1 GKZ1
P40 A8 GKZ1
4P40-1A1A1A1A1-GKZ1
5P40-A1A1A1A1A1-GKZ1
7P40-7*A1-GKZ1
