Hydraulic Engine 400cc For IH John Deere Sugar Cane Harvesters Tractors And Agricultural Machine
Hydraulic Engine 400cc For IH John Deere Sugar Cane Harvesters Tractors And Agricultural Machine
Hydraulic Engine 400cc For IH John Deere Sugar Cane Harvesters Tractors And Agricultural Machine
Hydraulic Engine 400cc For IH John Deere Sugar Cane Harvesters Tractors And Agricultural Machine
Hydraulic Engine 400cc For IH John Deere Sugar Cane Harvesters Tractors And Agricultural Machine
Hydraulic Engine 400cc For IH John Deere Sugar Cane Harvesters Tractors And Agricultural Machine
Specifications
Brand Name :
HANJIU
Model Number :
BMK2-400-F2-FE-SU
Certification :
CE
Place of Origin :
China
MOQ :
1 Pieces
Price :
Contact seller to ask
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
10000 pieces per year
Delivery Time :
35 work days
Packaging Details :
Box, Pallet
Item :
Sugar cane harvesters Drive Engine
Type :
Orbit motor
Direction :
Left and right
Displacement :
50cc - 497cc
Fit :
IH, John Deere
Used for :
Hydraulic System
Description

Hydraulic engine 400cc for IH John Deere Sugar cane harvesters, tractors and agricultural machine

Now for agricultural machinery equipment dealers, sugarcane harvester accessories dealers introduce this BMK2 motor

BMK2-400-F2-FE-SU, it's an equivalent for Eaton Char-lynn 104-3130

This hydraulic motor is widely used in IH and John Deere sugarcane harvesters

104-3130-006 BMK2-400 393.8 cm3/r STANDARD, 2 BOLT;
82.6. 13.59 106.4 SAE A		 31.75, 14 TOOTH, 12/24 DP 30 DEG.
WITH .375-16 , 33.0 MIn FULL SPLINE LENGTH		 .875-14 UNF-2B SAE O-RING
.4375-20 UNF-2B SAE O-RING

Hanjiu BMK2 = CHAR-LYNN 2000

Main Specifications:
Type BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2 BMK2
65 80 100 125 160 200 250 315 400 475
Geometric displacement
(cm3 /rev.)		 65 80 100.9 129.8 156.8 193.4 242.5 304.3 390.8 485
Max. speed (rpm) cont. 835 800 742 576 477 385 308 246 191 153
int. 990 980 924 720 713 577 462 365 287 230
Max. torque (N·m) cont. 185 235 295 385 455 540 660 765 775 845
int. 245 345 445 560 570 665 820 885 925 930
Max. pressure drop (MPa) cont. 20.5 21 21 21 20.5 20.5 20.5 21 15.5 12
int. 27.5 31 31 31 26 26 26 24 17 14
peak 31 31 31 31 31 31 31 31 20.5 17
Max. flow (L/min) cont. 55 65 75 75 75 75 75 75 75 75
int. 65 80 95 95 115 115 115 115 115 115
Weight (kg) 9.2 9.4 9.7 10 10.2 10.5 11 11.5 12 12.4
* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.
