101-1855-009 Low Speed High Torque Hydraulic Motor Charlynn H Series Medium Motor
101-1855-009 Low Speed High Torque Hydraulic Motor Charlynn H Series Medium Motor
101-1855-009 Low Speed High Torque Hydraulic Motor Charlynn H Series Medium Motor
101-1855-009 Low Speed High Torque Hydraulic Motor Charlynn H Series Medium Motor
101-1855-009 Low Speed High Torque Hydraulic Motor Charlynn H Series Medium Motor
101-1855-009 Low Speed High Torque Hydraulic Motor Charlynn H Series Medium Motor
101-1855-009 Low Speed High Torque Hydraulic Motor Charlynn H Series Medium Motor
101-1855-009 Low Speed High Torque Hydraulic Motor Charlynn H Series Medium Motor
Specifications
Brand Name :
HANJIU
Model Number :
BMPH / Char Lynn H Series
Certification :
CE
Place of Origin :
China
MOQ :
50 Pieces
Price :
Negotiable
Payment Terms :
L/C, T/T, D/A, D/P, Western Union
Supply Ability :
80000 Pieces One Year
Packaging Details :
Carton Box
Product Name :
BMPH50
Displacement :
50CC
Flnge :
4 flange
Power :
Hydraulic Oil
Features :
High Pressure
Shaft size :
25.4mm/1inch
Description

3.5in3/r Low Speed High Torque Hydraulic Motor 101-1855-009

charlynn H series medium motor

Hanjiu Hydraulic Motor BMPH50 = Char-Lynn 101-1855-009 Motor

Product details:

type BMPH
displacement 50cc
flange: 4-3/8-16 Square-flange , pilot Ø 44.4 2.8
shaft Shaft Ø25.4, cylindrical shaft with pin holeφ10.3/0.406"
oil port 1/2-14 NPTF, 7/16-20UNF

Designed for medium duty applications, these motors use industry-proven spool valve technology combined with state-of-the-art gerotors. In addition, a wide variety of mounting flanges, shafts, Ports and valving options provide design flexibility. Direction of shaft rotation and shaft speed can be controlled easily and smoothly throughout the speed range of the motor, and equipment can be driven direct, eliminating costly mechanical components.

Specification:

Type BMPH
36		 BMPH
50		 BMPH
80		 BMPH
100		 BMPH
125		 BMPH
160		 BMPH
200		 BMPH
250		 BMPH
315		 BMPH
400		 BMPH
500
Geometric displacement (cm3 /rev.) 36 51.7 77.7 96.2 120.2 157.2 194.5 240.3 314.5 389.5 486.5
Max. speed (rpm) cont. 1500 1150 770 615 490 383 310 250 192 155 120
int. 1650 1450 960 770 615 475 385 310 240 190 150
Max. torque (N·m) cont. 55 100 146 182 236 302 360 460 475 490 430
int. 76 128 186 227 290 370 440 570 555 580 560
peak 96 148 218 264 360 434 540 670 840 840 780
Max. output (kW) cont. 8 10 10 11 10 10 10 8.5 7 6 6
int. 11.5 12 12 13 12 12 12 10.5 8.5 7 7
Max. pressure drop (MPa) cont. 12.5 14 14 14 14 14 14 14 12 9.5 7
int. 16.5 17.5 17.5 17.5 17.5 17.5 17.5 17.5 14 11.5 9
peak 22.5 22.5 22.5 22.5 22.5 22.5 22.5 22.5 22.5 18 13
Max. flow (L/min) cont. 55 60 60 60 60 60 60 60 60 60 60
int. 60 75 75 75 75 75 75 75 75 75 75
Weight (kg) 5.6 6 5.7 5.9 6 6.2 6.4 7 6.9 7.4 8

101-1855-009 Low Speed High Torque Hydraulic Motor Charlynn H Series Medium Motor

101-1855-009 Low Speed High Torque Hydraulic Motor Charlynn H Series Medium Motor

101-1855-009 Low Speed High Torque Hydraulic Motor Charlynn H Series Medium Motor

We are professional manufacturer produce Hydraulic Orbital Motors,our motors match and Char Lynn and M+S and Brevini motor series

Please contact me for more details.

Tracy whatsapp/wechat :+8618132660311

Shijiazhuang Hanjiu Technology Co.,Ltd
