Rock Drilling Solutions Spare Parts 3115347383 Disc Valve Motor
Rock Drilling Solutions Spare Parts 3115347383 Disc Valve Motor
Rock Drilling Solutions Spare Parts 3115347383 Disc Valve Motor
Rock Drilling Solutions Spare Parts 3115347383 Disc Valve Motor
Rock Drilling Solutions Spare Parts 3115347383 Disc Valve Motor
Rock Drilling Solutions Spare Parts 3115347383 Disc Valve Motor
Specifications
Brand Name :
HANJIU CHINA
Model Number :
BMSY
Certification :
CE
Place of Origin :
CHINA
MOQ :
100 Pieces
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, Payple
Supply Ability :
100000 pieces per year
Delivery Time :
25 - 35 work days
Packaging Details :
2pcs/32x32x17cm
Product :
Disc valve hydro motor
Apply To :
All Hydraulic rock drilling equipments
Flange :
4 hole, Rhomb
Shaft :
splined 14-DP12/24
Max Flow :
cont.75/int.90 L/min
Max Speed :
cont.470rpm,int.560rpm
Description

Rock Drilling Solutions Spare Parts Hydro Motor 3115347383 Replacement Parts Oem Parts

This type BMSY Motors can be widely used on rock drilling equipments

especially for ATLAS COPCO COP1840

also supply below OEM parts

3115347380

3115347381

3115347383

3115347385

The main specification

Type BMSY
BMSE
80		 BMSY
BMSE
100		 BMSY
BMSE
125		 BMSY
BMSE
160		 BMSY
BMSE
200		 BMSY
BMSE
250		 BMSY
BMSE
315		 BMSY
BMSE
375
Geometric displacement
(cm3 /rev.)		 80.6 100.8 125 157.2 200 252 314.5 370
Max. speed (rpm) cont. 800 748 600 470 375 300 240 200
int. 988 900 720 560 450 360 280 240
Max. torque (N·m) cont. 190 240 310 316 400 450 560 536
int. 240 300 370 430 466 540 658 645
peak 260 320 400 472 650 690 740 751
Max. output (kW) cont. 15.9 18.8 19.5 15.6 15.7 14.1 14.1 11.8
int. 20.1 23.5 23.2 21.2 18.3 17 18.9 17
Max. pressure drop (MPa) cont. 17.5 17.5 17.5 15 14 12.5 12 10
int. 21 21 21 21 16 16 14 12
peak 22.5 22.5 22.5 22.5 22.5 20 18.5 14
Max. flow (L/min) cont. 65 75 75 75 75 75 75 75
int. 80 90 90 90 90 90 90 90
Max. inlet pressure (MPa) cont. 25 25 25 25 25 25 25 25
int. 30 30 30 30 30 30 30 30
Weight (kg) 9.8 10 10.3 10.7 11.1 11.6 12.3 12.6

* Continuous pressure :Max. value of operating motor continuously.

* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.

* Peak pressure:Max. value of operating motor in 0.6 second per minute.Rock Drilling Solutions Spare Parts 3115347383 Disc Valve Motor

Rock Drilling Solutions Spare Parts 3115347383 Disc Valve Motor

Rock Drilling Solutions Spare Parts 3115347383 Disc Valve Motor

Rock Drilling Solutions Spare Parts 3115347383 Disc Valve Motor
