Galtech Q75 2 Banks Hydraulic Monoblock Valve 1/2 3/4 Ports Double Acting Spools
Galtech Q75 2 Banks Hydraulic Monoblock Valve 1/2 3/4 Ports Double Acting Spools
Galtech Q75 2 Banks Hydraulic Monoblock Valve 1/2 3/4 Ports Double Acting Spools
Galtech Q75 2 Banks Hydraulic Monoblock Valve 1/2 3/4 Ports Double Acting Spools
Galtech Q75 2 Banks Hydraulic Monoblock Valve 1/2 3/4 Ports Double Acting Spools
Galtech Q75 2 Banks Hydraulic Monoblock Valve 1/2 3/4 Ports Double Acting Spools
Specifications
Brand Name :
HANJIU
Model Number :
2P48F-OT
Certification :
CE
Place of Origin :
CHINA
MOQ :
100 Sets
Price :
Contact the seller to get a quote
Payment Terms :
L/C, T/T, Western Union, Western Union
Supply Ability :
300000 sets per year
Delivery Time :
25 - 35 work days
Packaging Details :
Carton, Box, Pallets
Item :
Hydraulic valves
Model :
q75
Apply to :
tractor attachment
Spool :
2 spool
MAax operation pressure :
250 bar
Nominal flow :
80 liters
Description

Galtech Q75 2 banks hydraulic monoblock valve with 1/2" & 3/4" Ports & Double Acting Spools

2P80F-OT = Q75/2F1SN103A1M1F3D

Flow 80 liters
Spool cylinder spool
Lever 2 lever
Founction spring return
Pressure Max 250 bar

  • Special High Resistance Cast Iron Body

  • Suitable for High Working Pressures up to 250 Bar

  • Standard Circuit in Parallel Allows Simultaneous Operations

  • Interchangeable Spools

  • Comes Complete with Nickel Plated Double Acting Spool (Other Spools on Request)

  • 3 Position Spring Centred Lever Assembly (Other Controls on Request)

  • 1/2" A, B,/ P, T Ports & 3/4"

  • 80 L/min Max Flow

  • Working Temperature: -30 to 80°C

  • 3 x 11mm Mounting Holes

  • Dimensions: 180mm Length x 232mm Height x 74mm Height

  • Weight: 7.60 Kg

Other spool and control configurations are available on request, please contact us for details.

More information about the product


Galtech Q75 2 Banks Hydraulic Monoblock Valve 1/2

Galtech Q75 2 Banks Hydraulic Monoblock Valve 1/2
