BMRS-375-H2-K-S Fluid Solution 375cc Lsht Motor 15.85GPM SAE A 2-Bolt Mount 1
BMRS-375-H2-K-S Fluid Solution 375cc Lsht Motor 15.85GPM SAE A 2-Bolt Mount 1
BMRS-375-H2-K-S Fluid Solution 375cc Lsht Motor 15.85GPM SAE A 2-Bolt Mount 1
BMRS-375-H2-K-S Fluid Solution 375cc Lsht Motor 15.85GPM SAE A 2-Bolt Mount 1
BMRS-375-H2-K-S Fluid Solution 375cc Lsht Motor 15.85GPM SAE A 2-Bolt Mount 1
BMRS-375-H2-K-S Fluid Solution 375cc Lsht Motor 15.85GPM SAE A 2-Bolt Mount 1
Specifications
Brand Name :
Hanjiu
Model Number :
BMRS Hydraulic motor
Certification :
CE,ISO9001
Place of Origin :
China
MOQ :
50 units
Price :
Negotiable
Payment Terms :
T/T, Western Union,Paypal .
Supply Ability :
100,000 units / Year
Delivery Time :
10-15 working days
Packaging Details :
Carton packing , with a tray or wooden box if needed .
Product name :
Hydraulic orbital Motors
Displacement :
36cc,50cc,80cc,100cc,125cc,160cc......500cc
Applications :
Agricultural machine, Lifting equipment
Replacement :
Hanjiu BMRS = DS, Eaton S,T series , M+S MR etc
Oil temperature :
normal-35℃-80℃
shaft :
cylindrical shaft φ25.4mm,woodruff key
Description

BMRS-375-H2-K-S : Fluid Solution LSHT Motor, 375cc, 15.85GPM, SAE A 2-Bolt Mount, 1"


The BMRS series advanced ROLORTORC gear set, shaft distribution fl ow, hydraulic motor is a compact, low noise, high efficient high torque low speed design. The ROLORTORC gear set also affords a reliable smooth start up at low pressure. BMRS motors are available with optional radial needle bearings (by special order) for side load applications. The low weight advanced construction design is manufactured in accordance with the requirements of ISO 9000-2000 quality system.

This BMRS motors is interchangeable for Parter TE/TF motor, Charlynn H/S/T motor

Details as below:

  • Port Size #10 SAE (5/8")
  • Shaft Size 1" Bore x 1/4" Key
  • Shaft Type Woodruff Keyed
  • Port Location Side Ported
  • Flow Rating 60
  • Pressure Rating 15
  • Displacement 381.4
  • Max Speed 190
  • Service Parts BMRS Seal Kit
  • Country of Manufacture China
  • Height 5.17
  • Length 6.26
  • Width 3.81
  • Weight 20.9



Main Specifications:

Technical data for BMR with 25 and 1 in and 1 in splined and 28.56 tapered shaft:

Type BMR
BMRS
36		 BMR
BMRS
50		 BMR
BMRS
80		 BMR
BMRS
100		 BMR
BMRS
125		 BMR
BMRS
160		 BMR
BMRS
200		 BMR
BMRS
250		 BMR
BMRS
315		 BMR
BMRS
375
Geometric displacement (cm3 /rev.) 36 51.7 81.5 102 127.2 157.2 194.5 253.3 317.5 381.4
Max. speed (rpm) cont. 1085 960 750 600 475 378 310 240 190 155
int. 1220 1150 940 750 600 475 385 300 240 190
Max. torque (N·m) cont. 72 100 195 240 300 360 360 390 390 365
int. 83 126 220 280 340 430 440 490 535 495
peak 105 165 270 320 370 460 560 640 650 680
Max. output (kW) cont. 8.5 9.5 12.5 13 12.5 12.5 10 7 6 5
int. 9.8 11.2 15 15 14.5 14 13 9.5 9 8
Max. pressure drop (MPa) cont. 14 14 17.5 17.5 17.5 16.5 13 11 9 7
int. 16.5 17.5 20 20 20 20 17.5 15 13 10
peak 22.5 22.5 22.5 22.5 22.5 22.5 22.5 20 17.5 15
Max. flow (L/min) cont. 40 50 60 60 60 60 60 60 60 60
int. 45 60 75 75 75 75 75 75 75 75
Weight (kg) 6.5 6.7 6.9 7 7.3 7.6 8 8.5 9 9.5


BMRS-375-H2-K-S Fluid Solution 375cc Lsht Motor 15.85GPM SAE A 2-Bolt Mount 1BMRS-375-H2-K-S Fluid Solution 375cc Lsht Motor 15.85GPM SAE A 2-Bolt Mount 1BMRS-375-H2-K-S Fluid Solution 375cc Lsht Motor 15.85GPM SAE A 2-Bolt Mount 1

BMRS-375-H2-K-S Fluid Solution 375cc Lsht Motor 15.85GPM SAE A 2-Bolt Mount 1


Applications :

  • Construction equipment
  • Agricultural equipment
  • Material handling & Lifting equipment
  • Forestry equipment
  • Lawn and turf equipment
  • Special purpose
  • Machine tools and stationary equipment
  • Marine equipment
