BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
Specifications
Brand Name :
HANJIU CHINA
Model Number :
BMSY-315-E2-T3-D
Certification :
CE
Place of Origin :
CHINA
MOQ :
100 Pieces
Price :
Contact the seller to ask
Payment Terms :
L/C, D/A, T/T, Western Union, Payple
Supply Ability :
100000 pieces per year
Delivery Time :
25 - 35 work days
Packaging Details :
Box, Pallet
Item :
Hydraulic Motor
Type :
Low speed high torque
Flange :
2 hole, Rhomb
Shaft :
Taper
Description

BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation

BMSY introduction:

This motor is a hydraulic disc motor, because it's widely used on kind of drills of Agricultural,Farm, Construction, Industrial and heavy machineries. it has numerous applications at any rolling, lifting, conveying applications. It's also called orbit hydraulic motor, or orbital motor, or Low Speed High Torque type motor, also disc valve hydraulic motors.

Main Specifications:
Type BMSY
BMSE
80		 BMSY
BMSE
100		 BMSY
BMSE
125		 BMSY
BMSE
160		 BMSY
BMSE
200		 BMSY
BMSE
250		 BMSY
BMSE
315		 BMSY
BMSE
375
Geometric displacement
(cm3 /rev.)		 80.6 100.8 125 157.2 200 252 314.5 370
Max. speed (rpm) cont. 800 748 600 470 375 300 240 200
int. 988 900 720 560 450 360 280 240
Max. torque (N·m) cont. 190 240 310 316 400 450 560 536
int. 240 300 370 430 466 540 658 645
peak 260 320 400 472 650 690 740 751
Max. output (kW) cont. 15.9 18.8 19.5 15.6 15.7 14.1 14.1 11.8
int. 20.1 23.5 23.2 21.2 18.3 17 18.9 17
Max. pressure drop (MPa) cont. 17.5 17.5 17.5 15 14 12.5 12 10
int. 21 21 21 21 16 16 14 12
peak 22.5 22.5 22.5 22.5 22.5 20 18.5 14
Max. flow (L/min) cont. 65 75 75 75 75 75 75 75
int. 80 90 90 90 90 90 90 90
Max. inlet pressure (MPa) cont. 25 25 25 25 25 25 25 25
int. 30 30 30 30 30 30 30 30
Weight (kg) 9.8 10 10.3 10.7 11.1 11.6 12.3 12.6

* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.

BMSY
BMSYS
160
BMSY
BMSYS
80
BMSY
BMSYS
100
BMSY
BMSYS
125
BMSY
BMSYS
200
BMSY
BMSYS
250
BMSY
BMSYS
315
BMSY
BMSYS
400
BMSY
BMSYS
475

BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation

BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation

BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation

More flange, shaft, oil ports, displacement can be provided as below:

BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation

BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation

BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation

BMSY Hydraulic Motor, BMSY-315-E2-T3-D, 315 ml/r, 2 bolt flange, Cone-shaft, G1/2 port, standard rotation
