BMRS-375 Low Speed High Torque Hydraulic Motor 4 Bolt Mount 160 RPM Straight Key Shaft
BMRS-375 Low Speed High Torque Hydraulic Motor 4 Bolt Mount 160 RPM Straight Key Shaft
BMRS-375 Low Speed High Torque Hydraulic Motor 4 Bolt Mount 160 RPM Straight Key Shaft
BMRS-375 Low Speed High Torque Hydraulic Motor 4 Bolt Mount 160 RPM Straight Key Shaft
BMRS-375 Low Speed High Torque Hydraulic Motor 4 Bolt Mount 160 RPM Straight Key Shaft
BMRS-375 Low Speed High Torque Hydraulic Motor 4 Bolt Mount 160 RPM Straight Key Shaft
BMRS-375 Low Speed High Torque Hydraulic Motor 4 Bolt Mount 160 RPM Straight Key Shaft
BMRS-375 Low Speed High Torque Hydraulic Motor 4 Bolt Mount 160 RPM Straight Key Shaft
Specifications
Brand Name :
Hanjiu
Model Number :
BMRS Hydraulic motor
Certification :
CE,ISO9001
Place of Origin :
China
MOQ :
50 units
Price :
Negotiable
Payment Terms :
T/T, Western Union,Paypal .
Supply Ability :
100,000 units / Year
Delivery Time :
10-15 working days
Packaging Details :
Carton packing , with a tray or wooden box if needed .
Product name :
Hydraulic orbital Motors
Displacement :
375CC
Applications :
Agricultural machine, drilling machines
Material :
cast iron
Oil temperature :
normal-35℃-80℃
shaft :
straight key shaft 25mm
Description

BMRS-375 Low Speed High Torque Hydraulic Motor 4 Bolt Mount 160 RPM,Straight key shaft

Features:

  • Shaft: φ25.4mm woodruff key
  • Flange: 4 bolt Mounting
  • Ports: 7/8-14 O-ring
  • Drain: 7/16-20UNF
  • Corrosion-resistant Black Paint

Technical Specifications for BMRS-375-H4-K-S

  • Displacement: 22.7 in³/rev (375 cm³/rev)
  • Max Speed: 155 rpm (cont) / 190 rpm (int)
  • Max Torque: 365 N.M (cont) / 495 N.M (int)
  • Max Differential: 7.0MPA (cont) / 10MPA (int)
  • Max Flow: 60l/min (cont) / 75l/min (int)

Drop-In Replacement for:

  • Char-Lynn 103- SERIES


Main Specifications:

Technical data for BMRS with 25 and 1 in and 1 in splined and 28.56 tapered shaft:

Type BMR
BMRS
36		 BMR
BMRS
50		 BMR
BMRS
80		 BMR
BMRS
100		 BMR
BMRS
125		 BMR
BMRS
160		 BMR
BMRS
200		 BMR
BMRS
250		 BMR
BMRS
315		 BMR
BMRS
375
Geometric displacement (cm3 /rev.) 36 51.7 81.5 102 127.2 157.2 194.5 253.3 317.5 381.4
Max. speed (rpm) cont. 1085 960 750 600 475 378 310 240 190 155
int. 1220 1150 940 750 600 475 385 300 240 190
Max. torque (N·m) cont. 72 100 195 240 300 360 360 390 390 365
int. 83 126 220 280 340 430 440 490 535 495
peak 105 165 270 320 370 460 560 640 650 680
Max. output (kW) cont. 8.5 9.5 12.5 13 12.5 12.5 10 7 6 5
int. 9.8 11.2 15 15 14.5 14 13 9.5 9 8
Max. pressure drop (MPa) cont. 14 14 17.5 17.5 17.5 16.5 13 11 9 7
int. 16.5 17.5 20 20 20 20 17.5 15 13 10
peak 22.5 22.5 22.5 22.5 22.5 22.5 22.5 20 17.5 15
Max. flow (L/min) cont. 40 50 60 60 60 60 60 60 60 60
int. 45 60 75 75 75 75 75 75 75 75
Weight (kg) 6.5 6.7 6.9 7 7.3 7.6 8 8.5 9 9.5


BMRS-375 Low Speed High Torque Hydraulic Motor 4 Bolt Mount 160 RPM Straight Key ShaftBMRS-375 Low Speed High Torque Hydraulic Motor 4 Bolt Mount 160 RPM Straight Key ShaftBMRS-375 Low Speed High Torque Hydraulic Motor 4 Bolt Mount 160 RPM Straight Key Shaft

Applications:
• Agricultural augers,harvesters, seeders
• Car wash brushes
• Food processing
• Railroad maintenance equipment
• Machine tools
• Conveyors
• Industrial sweepers and floor polishers
• Saw mill works
• Turf equipment
• Concrete and asphalt equipment
• Skid steer attachments
