White 11029276 OMR F 200 Hydraulic Motor With Brake Release Connection G ¼ SAE 6B Spline Shaft
White 11029276 OMR F 200 Hydraulic Motor With Brake Release Connection G ¼ SAE 6B Spline Shaft
White 11029276 OMR F 200 Hydraulic Motor With Brake Release Connection G ¼ SAE 6B Spline Shaft
White 11029276 OMR F 200 Hydraulic Motor With Brake Release Connection G ¼ SAE 6B Spline Shaft
White 11029276 OMR F 200 Hydraulic Motor With Brake Release Connection G ¼ SAE 6B Spline Shaft
White 11029276 OMR F 200 Hydraulic Motor With Brake Release Connection G ¼ SAE 6B Spline Shaft
White 11029276 OMR F 200 Hydraulic Motor With Brake Release Connection G ¼ SAE 6B Spline Shaft
White 11029276 OMR F 200 Hydraulic Motor With Brake Release Connection G ¼ SAE 6B Spline Shaft
Specifications
Brand Name :
HANJIU
Model Number :
BMR200
Certification :
CE
Place of Origin :
China
MOQ :
20 Pieces
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, Payple
Supply Ability :
300000 pieces per year
Delivery Time :
25-30 work days
Packaging Details :
1 pc/ inner carton, 3 pcs/ outer carton, 27x40x14cm, transport with wooden pallet, 1500 pcs/ 20GP, 3000 pcs/ 40GP
Type :
Hydraulic Oil Motor
material :
cast iron
Model No. :
bmr-bk3b-200-2edgn1
Displacement :
200CC
Speed :
310 RPM - 385 RPM
Flow :
60 lpm -75 lpm
pressure :
17.5mpa-22.5mpa
output :
10-13kw
Description

White 11029276 OMR F 200 Hydraulic Motor with Brake release connection G ¼, SAE 6B spline shaft

Specifications:

  1. order type 11029276=bmr-bk3b-200-2edgn1
  2. displacement = 200cc
  3. 2 bolt standard flange
  4. SAE 6B shaft
  5. G1/2 Manifold Mount, 4-M8, G1/4 port threads and drain ports
  6. brake release port G1/4



Specifications:

Main Specifications:

Technical data for BMR with 25 and 1 in and 1 in splined and 28.56 tapered shaft:

Type BMR
Bk3
36		 BMR
Bk3
50		 BMR
Bk01
80		 BMR
Bk3
100		 BMR
Bk01
125		 BMR
Bk3
160		 BMR
Bk3
200		 BMR
Bk3
250		 BMR
Bk3
315		 BMR
Bk3
375
Geometric displacement (cm3 /rev.) 36 51.7 81.5 102 127.2 157.2 194.5 253.3 317.5 381.4
Max. speed (rpm) cont. 1085 960 750 600 475 378 310 240 190 155
int. 1220 1150 940 750 600 475 385 300 240 190
Max. torque (N·m) cont. 72 100 195 240 300 360 360 390 390 365
int. 83 126 220 280 340 430 440 490 535 495
peak 105 165 270 320 370 460 560 640 650 680
Max. output (kW) cont. 8.5 9.5 12.5 13 12.5 12.5 10 7 6 5
int. 9.8 11.2 15 15 14.5 14 13 9.5 9 8
Max. pressure drop (MPa) cont. 14 14 17.5 17.5 17.5 16.5 13 11 9 7
int. 16.5 17.5 20 20 20 20 17.5 15 13 10
peak 22.5 22.5 22.5 22.5 22.5 22.5 22.5 20 17.5 15
Max. flow (L/min) cont. 40 50 60 60 60 60 60 60 60 60
int. 45 60 75 75 75 75 75 75 75 75
Weight (kg) 6.5 6.7 6.9 7 7.3 7.6 8 8.5 9 9.5


White 11029276 OMR F 200 Hydraulic Motor With Brake Release Connection G ¼ SAE 6B Spline ShaftWhite 11029276 OMR F 200 Hydraulic Motor With Brake Release Connection G ¼ SAE 6B Spline Shaft

When choosing an orbital motor, consider the following factors

Displacement Determines the amount of fluid displaced per revolution.

Operating pressure Affects motor torque and speed.

Speed The desired rotational speed of the output shaft.

Torque The required output force.

Efficiency The desired power conversion efficiency.

Mounting options Compatibility with your equipment.

Environmental conditions The operating environment's impact on the motor.

Would you like to provide more details about your specific application or requirements This information can help me recommend suitable orbital motor options and potential suppliers.

Please feel free to ask any further questions you may have.

This is talk new business chance, new profit growth methods, while maintain and carry forward your public praise. We, HANJIU, hydraulic manufacturer from China are willing to try to be your another choice.
