Specifications
Brand Name :
Zoyo
Model Number :
ZY009601
Certification :
ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
Place of Origin :
Hangzhou, CHINA
MOQ :
Flexible MOQ
Price :
$2~$500 per piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5k-20k pieces per day
Delivery Time :
3-4 weeks
Packaging Details :
CUSTOMIZED
Size(inch) :
0.96
Resolution :
128*64
Active Area(mm) :
19.26*1.41
Operating Temperature :
-20℃～70℃
Description
GENERAL SPECIFICATIONS
Item Specification Unit Note
Screen Size 0.96
Resolution 128*64 pixels
Operating Temperature ‐20℃~70℃
Storage Temperature ‐30℃~80℃
Module Size Horizontal (H) 26.7 mm typ
Vertical (V) 19.26
Thickness (T) 1.41
Active Area Horizontal 21.744 mm
Vertical 10.864
Interface Type MCU/4SPI
Application Blood Glucose Meter

The difference between PMOLED and AMOLED

Feature PMOLED AMOLED
Matrix Type Passive Matrix Active Matrix
Control Mechanism Sequential control of rows/columns Individual pixel control via TFTs
Resolution Lower Higher
Brightness/Contrast Good, but less uniform Superior brightness and contrast
Refresh Rate Lower, potential flickering Higher, suitable for dynamic content
Power Consumption Higher for larger/bright content More efficient, especially with dark content
Complexity/Cost Simpler, cheaper More complex, more expensive
Typical Applications Small, simple displays High-end, high-resolution displays

Our Service:

Technical Support

  • Customer Service: Access to customer support for addressing queries and issues.
  • Engineering Support: Direct contact with technical engineers for complex integration challenges or custom requirements.

Firmware Updates

  • Regular Updates: Provision of firmware updates to ensure compatibility and performance improvements.
  • Update Instructions: Clear instructions on how to perform firmware updates.

Compliance and Certification Documentation

  • Regulatory Compliance: Information and certification documents for compliance with relevant standards (e.g., CE, RoHS).
  • Quality Assurance: Documentation on quality control processes and product reliability testing.

Mechanical Drawings and 3D Models

  • CAD Files: 3D models and detailed mechanical drawings to aid in the physical design and integration of the display into the end product.
  • Mounting Templates: Templates to assist with precise placement and mounting of the display.
