400*300mm P1.56 UHD LED Display Indoor Full Color LED Video Wall Display
400*300mm P1.56 UHD LED Display Indoor Full Color LED Video Wall Display
Specifications
Brand Name :
PRT
Model Number :
P1.56
Certification :
CE RoHs FCC
Place of Origin :
Shenzhen China
MOQ :
1 square meters
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000 sq.m per month
Delivery Time :
15 work days
Packaging Details :
wooden case or flight case
Pixel pitch :
1.56mm
Module size :
200 * 300 mm
LED component :
SMD 1R1G1B
Scanning mode :
1/27 scan
Driving IC :
MBI5153 or defined
Maintain :
back access
Description

400 * 300mm P1.56 UHD LED Display for indoor full color video wall


Application:

Widely used for indoor meeting room, studio room, control center, command room where need high definition display vision and accurate data display


Function & Advantage

1. Cabinets are made of die-casting aluminium, can be spliced with no crack.
2. SMD three-in-one technology with high brightness makes the display have a ultra-wide view & vivid image when in use.
3. Work normally without air conditioning and fans for low power consumption.

4. Cabinet size with 400 * 300mm in 4:3 ratio for different screen sizes, light weight, easy to move and install

5. Package with wooden case or customized


Our service:

1. Your inquiry about our products or the price will be replied within 24 hours!
2. We provide 2 years for warranty and lifelong maintaining , you will appreciate our warm after-sale service.
3. We will delivery goods as you demand , you can choose the cheaper and more convenient way!
4. We can provide mature customised solution for you.



Related parameters for reference,please contact us for details.

DESCRIPTION:PH1.56 Indoor
No.ParameterSpecification
1Pixel Pitch(mm)1.56
2Pixel Density409600dots/m²
3LED TypeSMD1010 (black)
4LED Wave Length(nm)R:620-625/G:517.5-520/B:465-467.5
5LED Luminous Intensity(mcd)R:100~130/G:120~156/B:20~26
6Viewing Angle140°
7Brightness 1000cd/m²
8Drive Method1/27 scan
9Driving ICMBI5153
10Color Depth16bit
11Refresh Rate(Hz)3840
12Frame Rate(Hz)≥60
13Brightness AdjustmentManual/Auto/Program
14Module Size(mm)200×300
15Module Resolution(dots)128×192
16Cabinet Size(mm)400×300
17Cabinet Display Resolution(dots)256×192
18Cabinet Type and MaterialDie-casting Aluminum
19Cabinet Weight(Kg)6.5 kg
20Power Supply5.0V 60A
21Voltage(V)AC 110~220V
22Avg. Power Consumption 400W/m²
23Max. Power Consumption900W/m²
24Service AccessBack maintenance
25IP GradeIP31
26Operating Temp/Humidity-20ºC~50ºC, 10~90%RH
27Storage Temp/Humidity-40ºC~60ºC, 10~90%RH
28Lifetime(Normal Temp)≥50000H
29System ControlNova/Linsn/Colorlight
30Compliant StandardCCC,CE,RoHs,FCC
