Waterproof Flexible LED Display P12.5 Indoor / Outdoor Event Soft LED Mesh Curtain
Waterproof Flexible LED Display P12.5 Indoor / Outdoor Event Soft LED Mesh Curtain
Specifications
Brand Name :
PRT
Model Number :
P12.5 curtain
Certification :
CE ROHS FCC
Place of Origin :
Shenzhen China(mainland)
MOQ :
5 sq.m
Payment Terms :
T/T, Western Union, MoneyGram,
Supply Ability :
3000 sq.m per month
Delivery Time :
15 work days
Packaging Details :
wooden case(4 cabinets into a case)
Product Mode :
P 12.5 soft curtain
Pixel density :
6400 dots/m2
Panel size :
L 300 mm x H 900 mm x D18 mm
Environment temperature :
- 40 deg / + 60 deg
Working voltage :
100-240 V/AC 50/60 HZ
Waterproof :
IP 65
Description

Waterproof P12.5 soft mesh curtain flexible led display for indoor outdoor event


Product Features:

1. Transparent design, small wind resistance, light transmittance rate reach to 30%, look light

2. Slim thickness, maximum thickness is 17mm and minimum thickness is only 7 mm

3. Beautiful appearance, easy band and change design, meet the demand of creative modelling

4. Using high quality SMD3528 lamp bead, greatly enhance the contrast for the product

5. Metal connection component, one second fast locking installation, save time

6. Light weight, one unit weight only with 2.5kgs

7. IP grade reach IP65, can use for outdoor environment

Our service:

1. We can provide customers a comprehensive solution delivery of series-related products.

2. We can provide customers high quality products which allow them to scream.

3. We can provide custom-made service.

4. We can provide customers one year free warranty, and support renewals extended.

5. We can provide customers the free installation guidance and technical support.

6. We are willing to provide any countries and regions in the world with products and technical support. At present, our product has covered more than 100 countries and regions.

Packaging Details: packing in wooden box or flight case.

Delivery Time: 10-15days

Technical parameters:

Type Number P12.5 flexible curtain Unit module composition L1×H6 moudle
Pixel pitch(MM) 12.5 Unit module pixel L24×H72 dot
LED Standard SMD3528 Max.power consumption 96W
Pixel composition 3 IN 1 Module material PC
Pixel density(dot/m2) 6400 Protection level IP 65
Demensions(mm) L300*W150 Viewing angle 110°
Module Power 6W Working temperature -20℃~+50℃
Module resolution(L×W) 24×12 Working humidity 10%~90% RH
Scan mode 1/6 Life span ≥30,000 hours
Grey 65536 Working voltage AC 220 V / (110V) ±15% , 47~63 HZ
Refresh rate(Hz) ≥2000 Signal transfer Lan cable
Brightness (CD/m2) 1000 Control system LED FLASH Computer Control System
Best viewing distance(M) 12 Computer platform Windows XP,Windows 7
Unit module dimension L300×H900mm Video Sources available DVD, VCD, VCR, TV, camera with PAL/NSTC
Control case size 535×200×150mm Electric case product code COL.C.006.1011
Control area L4×H3string/L2×H6string Control pixel L96×H216dot/L48×H432 dot
Control area dimension(mm) W1200×H2700MM/W600×H5400MM Control case max.power 1200W
Effetive control distance ≤ 100 M (by LAN) , ≥ 100 M (by fiber optic with multi-module or single module
