High Refresh P5 SMD Outdoor Advertising LED Display With High Resolution 40000 Dots
High Refresh P5 SMD Outdoor Advertising LED Display With High Resolution 40000 Dots
Specifications
Brand Name :
PRT
Model Number :
Pitch 5 mm
Certification :
CE ROHS FCC
Place of Origin :
Guangdong China
MOQ :
5 sq.m
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
5000 sq.m per month
Delivery Time :
15 work days
Packaging Details :
wooden case(4 cabinets into a case)
Product :
p5 outdoor display
Driving mode :
1/8 Scaning
Moduel size :
160 x 160 mm
LED chip :
epistar, smd 2727, smd 3535
Application :
media video advertisement, living broadcasting
Use voltage :
110 / 220 V adjustable
Description

High Refresh P5 SMD outdoor Advertising LED Display with high resolution 40000 dots

Packaging Details:

Wooden case & Flight case
About 110 m2 of outdoor screens for 20" container
About 140 m2 of indoor screens for 20" container

Delivery Time:

Shipped in 16 days after payment


Features:

  • Renowned brand of 3 in 1 SMD outdoor led display with excellent color uniformity contributes best image effect.
  • The mix of renowned branded SMD LED with advanced surface mounted process resulted in reliable usage life.
  • High brightness output is suitable for all kinds of match solutions, such as volleyball, basketball.
  • Over 1920HZ refresh rate produces super stable pictures without flicker, even on slow motion live video.

Mechanical Design

  • Distinctive soft mask and strong cabinet edge protection provide highly resistant ability to impact game.
  • DC power input support ensures safety in operation.
  • Adjustable vertical viewing angle makes installation process more flexible and reach different occasion needs.
  • Modular screens designed to be installed directly standing on the floor.
  • Experienced structure engineering team concentrates on designing convenient and easy installation cabinets with firmness.

Technical parameters for reference:

Pitch size 5 mm
Pixel configuration 1 Red, 1 Green ,1 Blue, SMD 3-in-1
Cabinet solution(W*H) 192 dots * 192 dots
Pixel density 40000 dots/sqm
Cabinet size(W*H) 960 mm* 960mm
Brightness(average) ≥6000 cd/ sqm
View angle(H/V) H/V 140/120 degree
Power consumption 100 W/sqm ~ 1200 W/sqm
Net weight 35 kg/sqm
Voltage 220V/110V±15% 50 Hz
Color scale 256~65536 degree /1.07 billion colors
Display mode VGA 640X480—VGA 1600X1024
Life span ≥100,000 hours
Refresh frame frequency ≥1920 HZ
Exchange frame speed >150 frames per second
Control distance ≤100M (Cat.5 without repeater) /500 M (multi-mode optical fiber)/20000m(single-mode optical fiber)
Operating temperature -25°C~+60°C
Operating humidity 10%—95% RH
Software LED studio
Best view distance >5m
Communication port VGA
Control mode Synchronous, real time with PC
Drive mode Constant current driving
Protection of power supply Overtemperature, overcurrent, overvoltage etc.
Operating system Windows 98/Me/2000/Xp,q1t
Brightness adjustment 100 levels automatically or by hand
Drive mode 1/8 scan, constant current




Befor offering price,please kindly confirm us some details if you don't mind:

1. What's the size of screen, cabinet you prefer?
2. What's the best viewing distance with your project?
3. What's the color of cabinet you need? any logo on back of cabinet?
4. When do you need to get goods? is this urgent?
5. Any special requests? such as video processor, hanging bar, flight case for package? please advise it as well.
